1GD-FTV Toyota 1GD-FTV
Модульний 4-циліндровий двигун з турбонаддувом, розроблений для високої ефективності та надійності.
74
Двигунів бренду
16
Модифікацій
Technical Specifications
| Engine Displacement | 2.8 л (2,755 см³) |
| Configuration | Inline-4 |
| Number of Cylinders | 4 |
| Valves per Cylinder | 4 |
| Power | 150 - 200 л.с. |
| Torque | 400 - 500 Н*м |
| Cylinder Bore | 92.00 мм |
| Piston Stroke | 103.00 мм |
| Compression Ratio | 15.6:1 |
| Firing Order | 1-3-4-2 |
| Fuel System | Common Rail Direct Injection |
| Aspiration | Turbocharged |
| Turbocharger | Variable Geometry Turbocharger |
| Intercooler | Yes |
| Maximum RPM | 3,400 об/хв |
| Max Torque RPM | 1,600 об/хв |
| Valve Train | DOHC |
| Timing Drive | Chain |
| Timing Chain Replacement | 300000 or as needed |
| Block Material | Cast Iron |
| Head Material | Aluminum |
| Engine Weight | 180 кг |
| Dimensions (L×W×H) | 600 × 600 × 700 мм |
| Lubrication System | Pressure lubrication |
| Cooling System | Liquid cooling |
Additional Information
| Engine Family | GD series |
| Manufacturing Plant | Toyota City, Japan |
Maintenance
| Engine Oil Capacity | 7.5 л (з фільтром: 8 л) |
| Recommended Viscosity | 5W-30, 10W-30 |
| Oil Standard | API SN, ACEA C3 |
| Recommended Brands | Toyota Genuine Oil, Mobil 1, Castrol Edge |
| Oil Change Interval | 15 000 км або 12 міс. |
| Oil Filter | 90915-YZZD3 |
| Air Filter |
17801-0L040
Заміна кожні 40 000 км |
| Паливний фільтр | 23390-0L020 |
| Cabin Filter | 88568-0L020 |
| Spark Plugs | |
| Coolant Capacity | 9 л |
| Coolant Type | Toyota Super Long Life Coolant (Toyota) |
| Coolant Change Interval | 240 000 км |
| Thermostat Opening Temperature | 88°C |
| Operating Temperature | 90°C |
| Max Operating Temperature | 110°C |
| Critical Temperature | 120°C |
| Annual Maintenance Cost | 600-900 USD |
Надійність
Очікуваний ресурс: 300 000 км
Типові проблеми
| Проблема | Серйозність | Пробіг | Вартість ремонту |
|---|---|---|---|
| Turbocharger failure | Medium | 150000-200000 km | $1000-2000 |
| EGR valve clogging | Medium | 100000-150000 km | $300-600 |
Відомі дефекти
- Some early models had issues with the fuel injectors
- Potential oil leaks from the timing cover
Розширення гарантії
- Toyota offers extended warranty for engine components up to 5 years/100000 miles
Потенціал тюнінгу
Потенціал тюнінгу: Medium | Макс. безпечна потужність: 320 л.с.
| Етап | Потужність | Крутний момент | Метод | Вартість |
|---|---|---|---|---|
| Stage 1 | 220 л.с. | 550 Н*м |
ECU remap only Вплив на надійність: Minimal |
$600 |
| Stage 2 | 260 л.с. | 600 Н*м |
ECU, Downpipe, Intake Необхідно: Upgraded intercooler, ECU remap Вплив на надійність: Low |
$1500 |
| Stage 3 | 300 л.с. | 700 Н*м |
- Необхідно: Bigger turbo, Upgraded fuel system Вплив на надійність: Medium |
$3000 |
Популярні модифікації
- ECU remap
- Upgraded intercooler
- High-performance exhaust system
Обмеження тюнінгу
- Fuel system limitations above 300hp
- Stock turbo limits at ~280hp
Детальні технічні характеристики
50
модифікацій
150–224
к.с.
Спільні характеристики
| Back suspension | Dependent, spring |
| Boost type | Turbocharged |
| Capacity | 2755 cm3 |
| Country | Japan |
| Cylinder layout | inline |
| Engine placement | Front, longitudinal |
| Engine type | Diesel |
| Front brakes | ventilated disc |
| Fuel | diesel |
| Number of cylinders | 4 |
| Valves per cylinder | 4 |
Модифікації двигуна
2.8 AT AWD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 9
2025–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1555 mm
Clearance
224 mm
Front track width
1530 mm
Height
1815 mm
Length
5320 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
265/60 R18, 265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Timing belt
DOHC
2.8 AT RWD (204 hp)
Привід Rear wheel drive
КПП Automatic
Hilux 9
2025–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1555 mm
Clearance
224 mm
Front track width
1530 mm
Height
1815 mm
Length
5320 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
265/60 R18, 265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Timing belt
DOHC
2.8 MT AWD (204 hp)
Привід All wheel drive (AWD)
КПП Manual
Hilux 9
2025–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
420 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
3400 RPM
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1555 mm
Clearance
224 mm
Front track width
1530 mm
Height
1815 mm
Length
5320 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
265/60 R18, 265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Timing belt
DOHC
2.8 MT RWD (204 hp)
Привід Rear wheel drive
КПП Manual
Hilux 9
2025–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
420 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
3400 RPM
transmission
Drive wheels
Rear wheel drive
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1555 mm
Clearance
224 mm
Front track width
1530 mm
Height
1815 mm
Length
5320 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
265/60 R18, 265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Timing belt
DOHC
2.8 AT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 70 Series [2th restyling]
2023–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
90 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3000 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
1600 RPM
fuel
City driving fuel consumption per 100 km
12.5 l
CO2 emissions
256 g/km
Highway driving fuel consumption per 100 km
9.1 l
Mixed driving fuel consumption per 100 km
9.9 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Clearance
200 mm
Height
1910 mm
Length
4235 mm
Number of doors
3
Wheelbase
2310 mm
Width
1870 mm
suspension
Front suspension
Dependent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/70 R16
other
Body type
Crossover
Car class
J
Number of seater
5
Timing belt
DOHC
2.8 AT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 70 Series [2th restyling]
2023–2026
204 hp
engine
Compression ratio
17.9
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
90 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3000 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
1600 RPM
fuel
City driving fuel consumption per 100 km
12.5 l
CO2 emissions
256 g/km
Highway driving fuel consumption per 100 km
9.1 l
Mixed driving fuel consumption per 100 km
9.9 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1420 mm
Clearance
235 mm
Curb weight
2350 kg
Front track width
1515 mm
Full weight
3300 kg
Height
2115 mm
Length
5140 mm
Number of doors
3
Wheelbase
2980 mm
Width
1790 mm
suspension
Front suspension
Dependent, spring
Rear brakes
drum
Steering wheel position
Left/Right
Wheel size
225/95 R16
other
Body type
Crossover
Car class
J
Number of seater
9, 11
Timing belt
SOHC
2.8 AT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 70 Series [2th restyling]
2023–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
130 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3000 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
1600 RPM
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1420 mm
Clearance
317 mm
Curb weight
2200 kg
Front track width
1515 mm
Height
1960 mm
Length
5235 mm
Number of doors
4
Wheelbase
3180 mm
Width
1790 mm
suspension
Front suspension
Dependent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/70 R16
other
Body type
Pickup
Car class
J
Number of seater
5
Timing belt
DOHC
2.8 AT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 70 Series [2th restyling]
2023–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
130 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3000 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
1600 RPM
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1420 mm
Clearance
316 mm
Curb weight
2145 kg
Front track width
1515 mm
Height
1970 mm
Length
5235 mm
Number of doors
2
Wheelbase
3180 mm
Width
1790 mm
suspension
Front suspension
Dependent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/70 R16
other
Body type
Pickup
Car class
J
Number of seater
2
Timing belt
DOHC
2.8 AT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado 250 Series
2023–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine model
1GD-FTV
Engine power
204 hp
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
fuel
City driving fuel consumption per 100 km
11.8 l
CO2 emissions
224 g/km
Highway driving fuel consumption per 100 km
7.9 l
Mixed driving fuel consumption per 100 km
9.1 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
8
dimensions
Clearance
221 mm
Curb weight
2285 kg
Height
1870 mm
Length
4920 mm
Number of doors
5
Wheelbase
2850 mm
Width
1980 mm
suspension
Front suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
other
Body type
Crossover
Car class
J
Flow calculation method
WLTP
Number of seater
5, 7
Timing belt
DOHC
2.8 AT AWD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 70 Series [2th restyling]
2023–2026
204 hp
engine
Compression ratio
17.9
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine power
204 hp
Fuel tank capacity
130 l
Injection type
direct injection (direct)
Max power (kW)
150 kW
Max power at RPM
3000 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
1600 RPM
fuel
City driving fuel consumption per 100 km
12.5 l
CO2 emissions
256 g/km
Highway driving fuel consumption per 100 km
9.1 l
Mixed driving fuel consumption per 100 km
9.9 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1460 mm
Clearance
200 mm
Curb weight
2300 kg
Front track width
1555 mm
Full weight
2575 kg
Height
1920 mm
Length
4890 mm
Number of doors
5
Wheelbase
2730 mm
Width
1870 mm
suspension
Front suspension
Dependent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/70 R16
other
Body type
Crossover
Car class
J
Number of seater
5
Timing belt
SOHC
2.8 AT AWD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 70 Series [2th restyling]
2023–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92 mm
Engine code
1GD-FTV
Engine power
204 hp
Fuel tank capacity
130 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3000 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
1600 RPM
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1420 mm
Clearance
316 mm
Curb weight
2145 kg
Front track width
1515 mm
Height
1970 mm
Length
5235 mm
Number of doors
2
Wheelbase
3180 mm
Width
1790 mm
suspension
Front suspension
Dependent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/70 R16
other
Body type
Pickup
Car class
J
Number of seater
2
Timing belt
DOHC
2.8 AT (204 hp)
Привід Rear wheel drive
КПП Automatic
Fortuner 2 [рест.]
2020–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
4000 RPM
Max trunk capacity
1950 l
Maximum torque
500 N*m
Min trunk capacity
297 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
13.6 l
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
9.3 l
Mixed driving fuel consumption per 100 km
10.9 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
225 mm
Curb weight
2225 kg
Front track width
1545 mm
Full weight
2735 kg
Height
1835 mm
Length
4795 mm
Number of doors
5
Wheelbase
2745 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
265/60 R18, 265/65 R17
other
Body type
Crossover
Car class
J
Disc size
7.5x17 ET30, 7.5x18 ET30, 8x19 ET30, 8x20 ET30
Number of seater
7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT 4WD (177 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado 150 Series [3th restyling]
2020–2024
177 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
177 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
130 kW
Max power at RPM
3400 RPM
Max trunk capacity
1934 l
Maximum torque
450 N*m
Min trunk capacity
621 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
performance
Acceleration (0-100 km/h)
12.7 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
9.2 l
CO2 emissions
194 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.3 l
Mixed driving fuel consumption per 100 km
7.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
215 mm
Curb weight
2165 kg
Front track width
1585 mm
Full weight
2990 kg
Height
1845 mm
Length
4840 mm
Number of doors
5
Wheelbase
2790 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Disc size
6.5x17 ET15, 7.5x17 ET25, 7.5x18 ET25, 7.5x19 ET25
Number of seater
5, 7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT 4WD (200 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 8 [2th restyling]
2020–2026
200 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
200 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
147 kW
Max power at RPM
3400 RPM
Maximum torque
400 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
performance
Acceleration (0-100 km/h)
10.0 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
8.9 l
CO2 emissions
209 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.4 l
Mixed driving fuel consumption per 100 km
8.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
227 mm
Curb weight
2155 kg
Front track width
1540 mm
Full weight
2910 kg
Height
1815 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Disc size
6x16 ET45, 6x17 ET50, 7.5x17 ET30, 7.5x18 ET30
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT 4WD (200 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado 150 Series [3th restyling]
2020–2024
200 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
200 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
147 kW
Max power at RPM
3400 RPM
Max trunk capacity
1934 l
Maximum torque
500 N*m
Min trunk capacity
621 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
9.9 s
Max speed
175 km/h
fuel
CO2 emissions
192 g/km
Emission standards
Euro 6
Mixed driving fuel consumption per 100 km
8.9 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
215 mm
Curb weight
2165 kg
Front track width
1585 mm
Full weight
2990 kg
Height
1845 mm
Length
4840 mm
Number of doors
5
Wheelbase
2790 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Disc size
6.5x17 ET15, 7.5x17 ET25, 7.5x18 ET25, 7.5x19 ET25
Number of seater
5, 7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT 4WD (200 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 8 [2th restyling]
2020–2026
200 hp
engine
Compression ratio
15.6
Cylinder bore
98 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
200 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
147 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
performance
Acceleration (0-100 km/h)
10.0 s
fuel
City driving fuel consumption per 100 km
8.9 l
CO2 emissions
209 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.4 l
Mixed driving fuel consumption per 100 km
8.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1760 mm
Clearance
375 mm
Curb weight
2640 kg
Front track width
1760 mm
Full weight
2910 kg
Height
1870 mm
Length
5330 mm
Number of doors
4
Wheelbase
3085 mm
Width
2910 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
315/70 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT 4WD (200 hp)
Привід All wheel drive (AWD)
КПП Automatic
Fortuner 2 [рест.]
2020–2026
200 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
200 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
147 kW
Max power at RPM
3400 RPM
Max trunk capacity
1950 l
Maximum torque
500 N*m
Min trunk capacity
297 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
10.8 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
13.6 l
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
9.3 l
Mixed driving fuel consumption per 100 km
10.9 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
225 mm
Curb weight
2225 kg
Front track width
1545 mm
Full weight
2735 kg
Height
1835 mm
Length
4795 mm
Number of doors
5
Wheelbase
2745 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
265/60 R18, 265/65 R17
other
Body type
Crossover
Car class
J
Disc size
7.5x17 ET30, 7.5x18 ET30, 8x19 ET30, 8x20 ET30
Number of seater
7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 8 [2th restyling]
2020–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
10.7 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
8.9 l
CO2 emissions
209 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.4 l
Mixed driving fuel consumption per 100 km
8.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
227 mm
Curb weight
2155 kg
Front track width
1540 mm
Full weight
2910 kg
Height
1815 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left
Wheel size
265/65 R17
other
Battery type
Lithium-ion (Li-ion)
Body type
Pickup
Car class
J
Disc size
6x16 ET45, 6x17 ET50, 7.5x17 ET30, 7.5x18 ET30
Flow calculation method
WLTP
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado 150 Series [3th restyling]
2020–2024
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Max trunk capacity
1934 l
Maximum torque
500 N*m
Min trunk capacity
621 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
9.9 s
Max speed
175 km/h
fuel
CO2 emissions
192 g/km
Emission standards
Euro 6
Mixed driving fuel consumption per 100 km
7.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
215 mm
Curb weight
2165 kg
Front track width
1585 mm
Full weight
2990 kg
Height
1845 mm
Length
4840 mm
Number of doors
5
Wheelbase
2790 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Disc size
6.5x17 ET15, 7.5x17 ET25, 7.5x18 ET25, 7.5x19 ET25
Number of seater
5, 7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 8 [2th restyling]
2020–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
10.7 s
Max speed
175 km/h
fuel
CO2 emissions
233 g/km
Emission standards
Euro 5
Mixed driving fuel consumption per 100 km
9.5 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
289 mm
Curb weight
2090 kg
Front track width
1535 mm
Full weight
3150 kg
Height
1810 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Disc size
6x17 ET50, 7.5x17 ET30, 7.5x18 ET30
Number of seater
4
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado 150 Series [3th restyling]
2020–2024
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Max trunk capacity
1434 l
Maximum torque
500 N*m
Min trunk capacity
381 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
12.7 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
9.5 l
CO2 emissions
212 g/km
Emission standards
Euro 6
Highway driving fuel consumption per 100 km
7.2 l
Mixed driving fuel consumption per 100 km
8.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
205 mm
Curb weight
2075 kg
Front track width
1585 mm
Full weight
2990 kg
Height
1830 mm
Length
4395 mm
Number of doors
3
Wheelbase
2450 mm
Width
1885 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Disc size
6.5x17 ET15, 7.5x17 ET25, 7.5x18 ET25, 7.5x19 ET25
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT AWD (200 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 8 [2th restyling]
2020–2026
200 hp
engine
Compression ratio
15.6
Cylinder bore
98 mm
Engine code
1GD-FTV
Engine power
200 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
147 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
performance
Acceleration (0-100 km/h)
10.0 s
fuel
City driving fuel consumption per 100 km
8.9 l
CO2 emissions
209 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.4 l
Mixed driving fuel consumption per 100 km
8.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1760 mm
Clearance
375 mm
Curb weight
2640 kg
Front track width
1760 mm
Full weight
2910 kg
Height
1870 mm
Length
5330 mm
Number of doors
4
Wheelbase
3085 mm
Width
2910 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
315/70 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT AWD (200 hp)
Привід All wheel drive (AWD)
КПП Automatic
Fortuner 2 [рест.]
2020–2026
200 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
200 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
147 kW
Max power at RPM
3400 RPM
Max trunk capacity
1950 l
Maximum torque
500 N*m
Min trunk capacity
297 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
10.8 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
13.6 l
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
9.3 l
Mixed driving fuel consumption per 100 km
10.9 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
225 mm
Curb weight
2225 kg
Front track width
1545 mm
Full weight
2735 kg
Height
1835 mm
Length
4795 mm
Number of doors
5
Wheelbase
2745 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
265/60 R18, 265/65 R17
other
Body type
Crossover
Car class
J
Number of seater
7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT AWD (200 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado 150 Series [3th restyling]
2020–2024
200 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
200 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
147 kW
Max power at RPM
3400 RPM
Max trunk capacity
1934 l
Maximum torque
500 N*m
Min trunk capacity
621 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
9.9 s
Max speed
175 km/h
fuel
CO2 emissions
192 g/km
Emission standards
Euro 6
Mixed driving fuel consumption per 100 km
8.9 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
215 mm
Curb weight
2165 kg
Front track width
1585 mm
Full weight
2990 kg
Height
1845 mm
Length
4840 mm
Number of doors
5
Wheelbase
2790 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Number of seater
5, 7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 D AT AWD (200 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 8 [2th restyling]
2020–2026
200 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
200 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
147 kW
Max power at RPM
3400 RPM
Maximum torque
400 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
performance
Acceleration (0-100 km/h)
10.0 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
8.9 l
CO2 emissions
209 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.4 l
Mixed driving fuel consumption per 100 km
8.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
227 mm
Curb weight
2155 kg
Front track width
1540 mm
Full weight
2910 kg
Height
1815 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 D AT AWD (200 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado 150 Series [3th restyling]
2020–2024
200 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
200 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
147 kW
Max power at RPM
3400 RPM
Max trunk capacity
1934 l
Maximum torque
500 N*m
Min trunk capacity
621 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
9.9 s
Max speed
175 km/h
fuel
CO2 emissions
192 g/km
Emission standards
Euro 6
Mixed driving fuel consumption per 100 km
8.9 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
215 mm
Curb weight
2165 kg
Front track width
1585 mm
Full weight
2990 kg
Height
1845 mm
Length
4840 mm
Number of doors
5
Wheelbase
2790 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Number of seater
5, 7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 D AT AWD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 8 [2th restyling]
2020–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
10.7 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
8.9 l
CO2 emissions
209 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.4 l
Mixed driving fuel consumption per 100 km
8.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
227 mm
Curb weight
2155 kg
Front track width
1540 mm
Full weight
2910 kg
Height
1815 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 D AT AWD (204 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado 150 Series [3th restyling]
2020–2024
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
204 hp
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Max trunk capacity
1934 l
Maximum torque
500 N*m
Min trunk capacity
621 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
9.9 s
Max speed
175 km/h
fuel
CO2 emissions
192 g/km
Emission standards
Euro 6
Mixed driving fuel consumption per 100 km
7.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
215 mm
Curb weight
2165 kg
Front track width
1585 mm
Full weight
2990 kg
Height
1845 mm
Length
4840 mm
Number of doors
5
Wheelbase
2790 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Number of seater
5, 7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 D AT AWD (224 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 8 [2th restyling]
2020–2026
224 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
224 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
165 kW
Max power at RPM
3000 RPM
Maximum torque
550 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
fuel
Emission standards
Euro 5
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
323 mm
Curb weight
2125 kg
Front track width
1540 mm
Full weight
3140 kg
Height
1815 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 D MT AWD (204 hp)
Привід All wheel drive (AWD)
КПП Manual
Hilux 8 [2th restyling]
2020–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
10.1 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
11.3 l
CO2 emissions
245 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
8.2 l
Mixed driving fuel consumption per 100 km
9.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
293 mm
Curb weight
2155 kg
Front track width
1540 mm
Full weight
2910 kg
Height
1815 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Timing belt
DOHC
2.8 MT 4WD (200 hp)
Привід All wheel drive (AWD)
КПП Manual
Hilux 8 [2th restyling]
2020–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
performance
Acceleration (0-100 km/h)
10.5 s
Max speed
195 km/h
fuel
City driving fuel consumption per 100 km
11.3 l
CO2 emissions
245 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
8.2 l
Mixed driving fuel consumption per 100 km
9.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
293 mm
Curb weight
2155 kg
Front track width
1540 mm
Full weight
2910 kg
Height
1815 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Timing belt
DOHC
2.8 MT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Manual
Land Cruiser Prado 150 Series [3th restyling]
2020–2024
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Max trunk capacity
1434 l
Maximum torque
420 N*m
Min trunk capacity
381 l
Stroke cycle
103.6 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
8.6 l
CO2 emissions
203 g/km
Emission standards
Euro 6
Highway driving fuel consumption per 100 km
7.1 l
Mixed driving fuel consumption per 100 km
7.7 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
205 mm
Curb weight
2065 kg
Front track width
1585 mm
Full weight
2990 kg
Height
1830 mm
Length
4395 mm
Number of doors
3
Wheelbase
2450 mm
Width
1885 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Disc size
6.5x17 ET15, 7.5x17 ET25, 7.5x18 ET25, 7.5x19 ET25
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 MT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Manual
Hilux 8 [2th restyling]
2020–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
10.1 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
11.3 l
CO2 emissions
245 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
8.2 l
Mixed driving fuel consumption per 100 km
9.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
293 mm
Curb weight
2155 kg
Front track width
1540 mm
Full weight
2910 kg
Height
1815 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
5
Timing belt
DOHC
2.8 MT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Manual
Hilux 8 [2th restyling]
2020–2026
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3400 RPM
Maximum torque
500 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2800 RPM
performance
Acceleration (0-100 km/h)
10.1 s
Max speed
175 km/h
fuel
CO2 emissions
236 g/km
Emission standards
Euro 5
Mixed driving fuel consumption per 100 km
8.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
289 mm
Curb weight
2090 kg
Front track width
1535 mm
Full weight
3150 kg
Height
1810 mm
Length
5325 mm
Number of doors
4
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Number of seater
4
Timing belt
DOHC
2.8 MT 4WD (204 hp)
Привід All wheel drive (AWD)
КПП Manual
Land Cruiser Prado 150 Series [3th restyling]
2020–2024
204 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
204 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
150 kW
Max power at RPM
3000 RPM
Max trunk capacity
1934 l
Maximum torque
420 N*m
Min trunk capacity
621 l
Stroke cycle
103.6 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
8.6 l
CO2 emissions
203 g/km
Emission standards
Euro 6
Highway driving fuel consumption per 100 km
7.1 l
Mixed driving fuel consumption per 100 km
7.7 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
215 mm
Curb weight
2140 kg
Front track width
1585 mm
Full weight
2990 kg
Height
1845 mm
Length
4840 mm
Number of doors
5
Wheelbase
2790 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Disc size
6.5x17 ET15, 7.5x17 ET25, 7.5x18 ET25, 7.5x19 ET25
Number of seater
5, 7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT (156 hp)
Привід Rear wheel drive
КПП Automatic
Hiace H300
2019–2026
156 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
156 hp
Injection type
Common rail (diesel)
Max power (kW)
115 kW
Max power at RPM
3400 RPM
Stroke cycle
103.6 mm
fuel
Mixed driving fuel consumption per 100 km
7.5 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1675 mm
Clearance
175 mm
Curb weight
2200 kg
Front track width
1670 mm
Full weight
3300 kg
Height
1990 mm
Length
5265 mm
Number of doors
3
Wheelbase
3210 mm
Width
1950 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
235/65 R16
other
Body type
Van
Car class
M
Disc size
7x16 ET55
Number of seater
2
Pitch Circle Diameter
DIA75.1 6x130 mm
Timing belt
DOHC
2.8 AT (177 hp)
Привід Rear wheel drive
КПП Automatic
Granvia 2
2019–2026
177 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
177 hp
Fuel tank capacity
70 l
Injection type
Common rail (diesel)
Max power (kW)
130 kW
Max power at RPM
3400 RPM
Maximum torque
450 N*m
Min trunk capacity
844 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
fuel
Mixed driving fuel consumption per 100 km
8.0 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1675 mm
Clearance
175 mm
Curb weight
2715 kg
Front track width
1675 mm
Full weight
3340 kg
Height
1990 mm
Length
5300 mm
Number of doors
5
Wheelbase
3210 mm
Width
1970 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
235/60 R17
other
Body type
Minivan
Car class
M
Disc size
7x17 ET55
Number of seater
6, 8
Timing belt
DOHC
2.8 AT (177 hp)
Привід Rear wheel drive
КПП Automatic
Hiace H300
2019–2026
177 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
177 hp
Injection type
Common rail (diesel)
Max power (kW)
130 kW
Max power at RPM
3400 RPM
Maximum torque
420 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2600 RPM
fuel
Mixed driving fuel consumption per 100 km
7.5 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1675 mm
Clearance
175 mm
Curb weight
2200 kg
Front track width
1670 mm
Full weight
3300 kg
Height
1990 mm
Length
5265 mm
Number of doors
3
Wheelbase
3210 mm
Width
1950 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
235/65 R16
other
Body type
Van
Car class
M
Disc size
7x16 ET55
Number of seater
2
Pitch Circle Diameter
DIA75.1 6x130 mm
Timing belt
DOHC
2.8 AT RWD (150 hp)
Привід Rear wheel drive
КПП Automatic
Hiace H300
2019–2026
150 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
150 hp
Fuel tank capacity
70 l
Injection type
Common rail (diesel)
Max power (kW)
110 kW
Max power at RPM
3600 RPM
Maximum torque
420 N*m
Min trunk capacity
844 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2200 RPM
fuel
Mixed driving fuel consumption per 100 km
8.7 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1675 mm
Clearance
175 mm
Curb weight
2685 kg
Front track width
1670 mm
Full weight
3500 kg
Height
1990 mm
Length
5300 mm
Number of doors
5
Wheelbase
3210 mm
Width
1970 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
235/65 R16
other
Body type
Minivan
Car class
M
Number of seater
9
Pitch Circle Diameter
DIA75.1 6x130 mm
Timing belt
DOHC
2.8 l, 150 hp, diesel, Automatic transmission, RWD
Привід Rear wheel drive
КПП Automatic
Hiace H300
2019–2026
150 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
150 hp
Fuel tank capacity
70 l
Injection type
Common rail (diesel)
Max power (kW)
110 kW
Max power at RPM
3600 RPM
Maximum torque
420 N*m
Min trunk capacity
844 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2200 RPM
fuel
Mixed driving fuel consumption per 100 km
8.7 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1675 mm
Clearance
175 mm
Curb weight
2685 kg
Front track width
1670 mm
Full weight
3500 kg
Height
1990 mm
Length
5300 mm
Number of doors
5
Wheelbase
3210 mm
Width
1970 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
235/65 R16
other
Body type
Minivan
Car class
M
Number of seater
9
Pitch Circle Diameter
DIA75.1 6x130 mm
Timing belt
DOHC
2.8 l, 150 hp, diesel, MT, RWD
Привід Rear wheel drive
КПП Manual
Hiace H300
2019–2026
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Fuel tank capacity
70 l
Injection type
Common rail (diesel)
Maximum torque
420 N*m
Min trunk capacity
844 l
Stroke cycle
103.6 mm
Turnover of maximum torque
2200 RPM
performance
Max speed
150 km/h
fuel
Mixed driving fuel consumption per 100 km
8.7 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1675 mm
Clearance
185 mm
Curb weight
2295 kg
Front track width
1670 mm
Full weight
3050 kg
Height
1990 mm
Length
5300 mm
Number of doors
5
Wheelbase
3210 mm
Width
1970 mm
suspension
Front suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left
Wheel size
235/65 R16
other
Body type
Minivan
Car class
M
Number of seater
9
Pitch Circle Diameter
DIA75.1 6x130 mm
Timing belt
DOHC
2.8 MT (156 hp)
Привід Rear wheel drive
КПП Manual
Hiace H300
2019–2026
156 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
156 hp
Injection type
Common rail (diesel)
Max power (kW)
115 kW
Max power at RPM
3400 RPM
Stroke cycle
103.6 mm
fuel
Mixed driving fuel consumption per 100 km
7.5 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1675 mm
Clearance
175 mm
Curb weight
2200 kg
Front track width
1670 mm
Full weight
3300 kg
Height
1990 mm
Length
5265 mm
Number of doors
3
Wheelbase
3210 mm
Width
1950 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
235/65 R16
other
Body type
Van
Car class
M
Disc size
7x16 ET55
Number of seater
2
Pitch Circle Diameter
DIA75.1 6x130 mm
Timing belt
DOHC
2.8 MT (177 hp)
Привід Rear wheel drive
КПП Manual
Hiace H300
2019–2026
177 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
177 hp
Injection type
Common rail (diesel)
Max power (kW)
130 kW
Max power at RPM
3400 RPM
Maximum torque
420 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2600 RPM
fuel
Mixed driving fuel consumption per 100 km
7.5 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1675 mm
Clearance
175 mm
Curb weight
2200 kg
Front track width
1670 mm
Full weight
3300 kg
Height
1990 mm
Length
5265 mm
Number of doors
3
Wheelbase
3210 mm
Width
1950 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
235/65 R16
other
Body type
Van
Car class
M
Disc size
7x16 ET55
Number of seater
2
Pitch Circle Diameter
DIA75.1 6x130 mm
Timing belt
DOHC
2.8 D AT AWD (177 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado J150 [2th restyling]
2015–2020
177 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
177 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
130 kW
Max power at RPM
3400 RPM
Max trunk capacity
1934 l
Maximum torque
450 N*m
Min trunk capacity
621 l
Presence of intercooler
Present
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
performance
Acceleration (0-100 km/h)
11.8 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
9.2 l
CO2 emissions
194 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.3 l
Mixed driving fuel consumption per 100 km
7.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1740 mm
Clearance
250 mm
Curb weight
2205 kg
Front track width
1740 mm
Full weight
2990 kg
Ground clearance
215 mm
Height
1955 mm
Length
4840 mm
Number of doors
5
Wheelbase
2815 mm
Width
2070 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
245/70 R17, 265/60 R18, 265/65 R17
other
Body type
Crossover
Car class
J
Front track
1585 mm
Number of seater
5, 7
Payload
825 kg
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1585 mm
Timing belt
DOHC
Turning circle
11.6 m
2.8 D MT AWD (177 hp)
Привід All wheel drive (AWD)
КПП Manual
Land Cruiser Prado J150 [2th restyling]
2017–2020
177 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
177 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power at RPM
to 3 400 RPM
Max trunk capacity
1934 l
Maximum torque
420 N*m
Min trunk capacity
621 l
Presence of intercooler
Present
Stroke cycle
103.6 mm
Turnover of maximum torque
2600 RPM
performance
Acceleration (0-100 km/h)
12.1 s
Max speed
175 km/h
fuel
CO2 emissions
194 g/km
Emission standards
Euro 5
Mixed driving fuel consumption per 100 km
7.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1585 mm
Clearance
215 mm
Curb weight
2165 kg
Front track width
1585 mm
Full weight
2990 kg
Ground clearance
215 mm
Height
1845 mm
Length
4840 mm
Number of doors
5
Wheelbase
2790 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Front track
1585 mm
Number of seater
5, 7
Payload
825 kg
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1585 mm
Timing belt
DOHC
Turning circle
11.6 m
2.8D AT AWD (177 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser Prado J150 [2th restyling]
2017–2020
177 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
177 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
130 kW
Max power at RPM
3400 RPM
Max trunk capacity
1434 l
Maximum torque
450 N*m
Min trunk capacity
381 l
Presence of intercooler
Present
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
performance
Acceleration (0-100 km/h)
12.7 s
Max speed
175 km/h
fuel
CO2 emissions
190 g/km
Emission standards
Euro 6
Mixed driving fuel consumption per 100 km
7.2 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1605 mm
Clearance
215 mm
Curb weight
2075 kg
Front track width
1605 mm
Full weight
2600 kg
Height
1830 mm
Length
4505 mm
Number of doors
3
Wheelbase
2450 mm
Width
1885 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Front track
1585 mm
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1585 mm
Timing belt
DOHC
2.8D MT AWD (177 hp)
Привід All wheel drive (AWD)
КПП Manual
Land Cruiser Prado J150 [2th restyling]
2017–2020
177 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
177 hp
Fuel tank capacity
87 l
Injection type
Common rail (diesel)
Max power (kW)
130 kW
Max power at RPM
3400 RPM
Max trunk capacity
1434 l
Maximum torque
420 N*m
Min trunk capacity
381 l
Presence of intercooler
Present
Stroke cycle
103.6 mm
Turnover of maximum torque
2600 RPM
performance
Acceleration (0-100 km/h)
12.1 s
Max speed
175 km/h
fuel
CO2 emissions
190 g/km
Emission standards
Euro 6
Mixed driving fuel consumption per 100 km
7.2 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1605 mm
Clearance
215 mm
Curb weight
2065 kg
Front track width
1605 mm
Full weight
2600 kg
Height
1830 mm
Length
4505 mm
Number of doors
3
Wheelbase
2450 mm
Width
1885 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Crossover
Car class
J
Front track
1585 mm
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1585 mm
Timing belt
DOHC
2.8 AT (174 hp)
Привід Rear wheel drive
КПП Automatic
Innova 2
2015–2026
174 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
174 hp
Fuel tank capacity
55 l
Injection type
Common rail (diesel)
Max power (kW)
128 kW
Max power at RPM
3400 RPM
Maximum torque
360 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
3400 RPM
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1530 mm
Curb weight
1820 kg
Front track width
1530 mm
Full weight
2450 kg
Height
1795 mm
Length
4735 mm
Number of doors
5
Wheelbase
2750 mm
Width
1830 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left
Wheel size
205/65 R16
other
Body type
Minivan
Car class
M
Disc size
6.5x17 ET35, 6x16 ET50, 7x17 ET42
Number of seater
7, 8
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Timing belt
DOHC
2.8 AT 4WD (177 hp)
Привід All wheel drive (AWD)
КПП Automatic
Hilux 8
2015–2020
177 hp
engine
Compression ratio
15.6
Cylinder bore
96.0 mm
Engine code
1GD-FTV
Engine model
1GD-FTV
Engine power
177 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
130 kW
Max power at RPM
3400 RPM
Maximum torque
450 N*m
Stroke cycle
103.0 mm
Turnover of maximum torque
2400 RPM
performance
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
10.9 l
CO2 emissions
223 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
7.1 l
Mixed driving fuel consumption per 100 km
8.5 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1550 mm
Clearance
227 mm
Curb weight
2150 kg
Front track width
1540 mm
Full weight
2910 kg
Height
1820 mm
Length
5335 mm
Number of doors
2
Wheelbase
3085 mm
Width
1855 mm
suspension
Front suspension
Independent, spring
Rear brakes
drum
Steering wheel position
Left/Right
Wheel size
265/65 R17
other
Body type
Pickup
Car class
J
Disc size
6x16 ET45, 6x17 ET50, 7.5x17 ET30, 7.5x18 ET30
Number of seater
3
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
2.8 AT AWD (177 hp)
Привід All wheel drive (AWD)
КПП Automatic
Fortuner 2
2015–2020
177 hp
engine
Compression ratio
15.6
Cylinder bore
92.0 mm
Engine code
1GD-FTV
Engine power
177 hp
Fuel tank capacity
80 l
Injection type
Common rail (diesel)
Max power (kW)
130 kW
Max power at RPM
3400 RPM
Maximum torque
450 N*m
Stroke cycle
103.6 mm
Turnover of maximum torque
2400 RPM
performance
Acceleration (0-100 km/h)
10.8 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
10.0 l
Highway driving fuel consumption per 100 km
9.0 l
Mixed driving fuel consumption per 100 km
8.5 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1685 mm
Clearance
270 mm
Curb weight
2335 kg
Front track width
1675 mm
Full weight
2735 kg
Height
1980 mm
Length
4795 mm
Number of doors
5
Wheelbase
2745 mm
Width
1960 mm
suspension
Front suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
265/60 R18, 265/65 R17
other
Body type
Crossover
Car class
J
Number of seater
7
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Timing belt
DOHC
Автомобілі з двигуном 1GD-FTV
Цей двигун встановлювався на 4 моделей
| Фото | Бренд | Модель | Генерація | Роки випуску |
|---|---|---|---|---|
|
Toyota | Fortuner | Fortuner II (AN160) | 2015 - present |
|
Toyota | HiAce | Hiace | 2006 - 2019 |
|
Немає фото
|
Toyota | HiAce | Hiace VI (H300) | 2019 - present |
|
Немає фото
|
Toyota | Hilux | Hilux VIII | 2015 - present |
|
Немає фото
|
Toyota | Tacoma | Tacoma III | 2015 - present |
Всі модифікації (16)
| Автомобіль | Генерація | Модифікація | Потужність | Коробка | Привід |
|---|---|---|---|---|---|
| Toyota Fortuner | Fortuner II (AN160) | 2.8L 4-циліндровий 177 л.с. 6-МКП 4x4 | 177 л.с. | 6-МКП | 4x4 |
| Toyota Fortuner | Fortuner II (AN160) | 2.8L 4-циліндровий 177 л.с. 6-Автомат 4x4 | 177 л.с. | 6-Автомат | 4x4 |
| Toyota Fortuner | Fortuner II (AN160) | 2.8L 4-циліндровий 204 л.с. 6-Автомат 4x4 | 204 л.с. | 6-Автомат | 4x4 |
| Toyota HiAce | Hiace | 2.8 1GD-FTV 177 л.с. 6-МКП 2WD | 177 л.с. | 6-МКП | 2WD |
| Toyota HiAce | Hiace | 2.8 1GD-FTV 177 л.с. 6-Автомат 2WD | 177 л.с. | 6-Автомат | 2WD |
| Toyota HiAce | Hiace | 2.8 1GD-FTV 177 л.с. 6-Автомат 4x4 | 177 л.с. | 6-Автомат | 4x4 |
| Toyota HiAce | Hiace VI (H300) | 2.8 D-4D Diesel 177 hp 6-MT 2WD | 177 л.с. | 6-MT | 2WD |
| Toyota HiAce | Hiace VI (H300) | 2.8 D-4D Diesel 177 hp 8-AT 2WD | 177 л.с. | 8-AT | 2WD |
| Toyota HiAce | Hiace VI (H300) | 2.8 D-4D Diesel 177 hp 6-MT 4x4 | 177 л.с. | 6-MT | 4x4 |
| Toyota HiAce | Hiace VI (H300) | 2.8 D-4D Diesel 177 hp 8-AT 4x4 | 177 л.с. | 8-AT | 4x4 |
| Toyota Hilux | Hilux VIII | 2.8 D-4D 177 л.с. 6-МКП 2WD | 177 л.с. | 6-МКП | 2WD |
| Toyota Hilux | Hilux VIII | 2.8 D-4D 177 л.с. 6-МКП 4x4 | 177 л.с. | 6-МКП | 4x4 |
| Toyota Hilux | Hilux VIII | 2.8 D-4D 177 л.с. 6-Автомат 2WD | 177 л.с. | 6-Автомат | 2WD |
| Toyota Hilux | Hilux VIII | 2.8 D-4D 177 л.с. 6-Автомат 4x4 | 177 л.с. | 6-Автомат | 4x4 |
| Toyota Tacoma | Tacoma III | 2.8L I4 Diesel 175 л.с. 6-Автомат 2WD | 175 л.с. | 6-Автомат | 2WD |
| Toyota Tacoma | Tacoma III | 2.8L I4 Diesel 175 л.с. 6-Автомат 4x4 | 175 л.с. | 6-Автомат | 4x4 |
Цікаві факти
- 1GD-FTV is known for its durability and efficiency.
- It features a variable geometry turbocharger for better performance.
Застосування
Всього виготовлено: загальна кількість випущених двигунів
| Автомобіль | Генерація | Роки | Потужність | Ринки |
|---|---|---|---|---|
| Toyota Hilux | Revo | 2015-present | 150hp/200hp | Australia, Asia, Europe |
| Toyota Fortuner | AN50 | 2015-present | 150hp/200hp | Australia, Asia, Europe |
Сумісні трансмісії: 6-speed Manual, 6-speed Automatic
Типи приводу: 4WD
Fuel Economy
| Fuel Type | Diesel |
| Consumption (City) | 10.5 л/100км |
| Consumption (Highway) | 7.5 л/100км |
| Consumption (Combined) | 9 л/100км |
| Real Consumption | 8.5 л/100км |
| Fuel Tank Capacity | 80 л |
| Range | 888 км |
| Cost per 100 km | 10-12 USD |
Emissions Standards
| Emission Standard | Euro 6 |
| CO₂ Emissions | 189 г/км |
| Particulate Filter (DPF) |
Present Регенерація кожні 150,000 км |
| AdBlue |
Required Витрата: 1 л/1000км |
Порівняння з конкурентами
| Двигун | Бренд | Об'єм | Потужність | Крутний момент |
|---|---|---|---|---|
| 2.8L I4 | Ford | 2,800 см³ | 180 л.с. | 450 Н*м |
| D4D | Toyota | 3,000 см³ | 173 л.с. | 420 Н*м |
Переваги
- Higher torque output compared to competitors
- Better fuel efficiency in real-world conditions
Недоліки
- Higher initial cost compared to some competitors
- Potential for turbo issues in high-mileage vehicles
Корисні ресурси
| Технічна документація | https://www.toyota-global.com/technical_specifications |
| Форуми та обговорення |
