2ZR-FXE Toyota 2ZR-FXE
Гібридний двигун з високою ефективністю, призначений для економії пального та зниження викидів.
74
Brand engines
27
Modifications
Technical Specifications
| Engine Displacement | 1.5 L (1,496 cc) |
| Configuration | Inline-4 |
| Number of Cylinders | 4 |
| Valves per Cylinder | 4 |
| Power | 73 - 100 л.с. |
| Torque | 111 - 142 Н*м |
| Cylinder Bore | 80.50 mm |
| Piston Stroke | 79.70 mm |
| Compression Ratio | 13.0:1 |
| Firing Order | 1-3-4-2 |
| Fuel System | Dual VVT-i |
| Aspiration | Naturally Aspirated |
| Intercooler | No |
| Maximum RPM | 6,000 rpm |
| Max Torque RPM | 4,400 rpm |
| Valve Train | DOHC |
| Timing Drive | Chain |
| Timing Chain Replacement | as needed |
| Block Material | Aluminum |
| Head Material | Aluminum |
| Engine Weight | 120 kg |
| Dimensions (L×W×H) | 600 × 500 × 600 mm |
| Lubrication System | Wet sump |
| Cooling System | Liquid cooling |
Additional Information
| Engine Family | ZR series |
| Manufacturing Plant | Takaoka, Japan |
Maintenance
| Engine Oil Capacity | 4.5 L (with filter: 4.8 L) |
| Recommended Viscosity | 0W-20 |
| Oil Standard | API SN |
| Recommended Brands | Toyota Genuine Oil, Mobil 1, Castrol Edge |
| Oil Change Interval | 15 000 km or 12 mo |
| Oil Filter | 90915-YZZD3 |
| Air Filter |
17801-0H010
Replace every 40 000 km |
| Spark Plugs |
Type: Iridium Part number: 90919-01240Gap: 1 mm Quantity: 4 pcs Replace every 100 000 km |
| Coolant Capacity | 6 L |
| Coolant Type | Toyota Super Long Life Coolant (Toyota) |
| Coolant Change Interval | 100 000 km |
| Thermostat Opening Temperature | 82°C |
| Operating Temperature | 90°C |
| Max Operating Temperature | 120°C |
| Critical Temperature | 130°C |
| Annual Maintenance Cost | 500-800 USD |
Reliability
Expected lifespan: 300 000 km
Common problems
| Problem | Severity | Mileage | Repair cost |
|---|---|---|---|
| Oil consumption issues | Medium | 100000-150000 km | $500-1000 |
| VVT-i actuator failure | Medium | 80000-120000 km | $300-600 |
Known defects
- Some early models had issues with oil consumption
- VVT-i system may require recalibration
Warranty extensions
- Toyota extended warranty for engine issues up to 10 years/150000 miles
Tuning potential
Tuning potential: Medium | Max. safe power: 150 hp
| Stage | Power | Torque | Method | Cost |
|---|---|---|---|---|
| Stage 1 | 110 hp | 150 Nm |
ECU remap only Reliability impact: Minimal |
$400 |
| Stage 2 | 125 hp | 165 Nm |
- Required: Cold air intake, ECU remap Reliability impact: Low |
$800 |
| Stage 3 | 140 hp | 180 Nm |
- Required: Turbocharger kit, ECU remap Reliability impact: Medium |
$3000 |
Popular modifications
- ECU remap
- Cold air intake
- Exhaust system upgrade
Tuning limitations
- Limited by stock internals
- Turbocharging may require extensive modifications
Детальні технічні характеристики
46
модифікацій
2–140
к.с.
Спільні характеристики
| Compression ratio | 13 |
| Country | Japan |
| Cylinder bore | 80.5 mm |
| Cylinder layout | inline |
| Engine code | 2ZR-FXE |
| Engine type | Hybrid |
| Front brakes | ventilated disc |
| Front suspension | Independent, spring |
| Number of cylinders | 4 |
| Timing belt | DOHC |
| Valves per cylinder | 4 |
Модифікації двигуна
1.8 CVT (122 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Corolla Cross 1 [рест.]
2024–2026
122 hp
engine
Boost type
none
Capacity
1797 cm3
Engine placement
Front, transverse
Engine power
122 hp
Fuel tank capacity
36 l
Injection type
distributed injection (multipoint)
Max power (kW)
90 kW
Max power at RPM
5200 RPM
Maximum torque
163 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
fuel
Fuel
95
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1560 mm
Front track width
1550 mm
Height
1620 mm
Length
4455 mm
Number of doors
5
Wheelbase
2640 mm
Width
1825 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
225/50 R18
other
Battery type
Nickel metal hydride (NiMH)
Body type
Crossover
Car class
C
Number of seater
5
1.8 CVT (140 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
C-HR 2
2023–2026
140 hp
engine
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
140 hp
Fuel tank capacity
43 l
Injection type
direct injection (direct)
Max power (kW)
103 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Min trunk capacity
360 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
9.9 s
Max speed
170 km/h
fuel
CO2 emissions
111 g/km
Emission standards
Euro 6
Fuel
95
Mixed driving fuel consumption per 100 km
5.0 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Height
1558 mm
Length
4360 mm
Number of doors
5
Wheelbase
2640 mm
Width
1830 mm
suspension
Back suspension
Independent, spring
Rear brakes
ventilated disc
Steering wheel position
Left
other
Battery type
Lithium-ion (Li-ion)
Body type
Crossover
Car class
C
Number of seater
5
1.8 AT (98 hp)
Привід Front wheel drive
КПП Automatic
Prius 5 (XW60)
2022–2026
98 hp
engine
Battery capacity
4.08 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
43 l
Injection type
combined injection (direct-distributed)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Max trunk capacity
1149 l
Maximum torque
142 N*m
Min trunk capacity
410 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
9.3 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.3 l
Fuel
95
Highway driving fuel consumption per 100 km
2.7 l
Mixed driving fuel consumption per 100 km
3.1 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1570 mm
Clearance
142 mm
Curb weight
1360 kg
Front track width
1567 mm
Full weight
1635 kg
Height
1430 mm
Length
4600 mm
Number of doors
5
Wheelbase
2750 mm
Width
1780 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/60 R17
other
Battery type
Lithium-ion (Li-ion)
Body type
Liftback
Car class
C
Number of seater
5
1.8 AT 4WD (98 hp)
Привід All wheel drive (AWD)
КПП Automatic
Prius 5 (XW60)
2022–2026
98 hp
engine
Battery capacity
4.08 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
43 l
Injection type
combined injection (direct-distributed)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Max trunk capacity
1149 l
Maximum torque
142 N*m
Min trunk capacity
410 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.6 l
Fuel
95
Highway driving fuel consumption per 100 km
2.9 l
Mixed driving fuel consumption per 100 km
3.3 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1570 mm
Clearance
142 mm
Curb weight
1420 kg
Front track width
1567 mm
Full weight
1695 kg
Height
1430 mm
Length
4600 mm
Number of doors
5
Wheelbase
2750 mm
Width
1780 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/50 R19, 195/60 R17
other
Battery type
Lithium-ion (Li-ion)
Body type
Liftback
Car class
C
Number of seater
5
1.8 CVT (140 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Corolla 12 (E210) [рест.]
2022–2026
140 hp
engine
Battery capacity
1.3 KW⋅h
Battery capacity (available)
1.0 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
140 hp
Fuel tank capacity
43 l
Injection type
distributed injection (multipoint)
Max power (kW)
103 kW
Max power at RPM
5200 RPM
Max trunk capacity
1606 l
Maximum torque
142 N*m
Min trunk capacity
596 l
Stroke cycle
88.3 mm
Turnover of maximum torque
5200 RPM
performance
Acceleration (0-100 km/h)
9.2 s
Max speed
180 km/h
fuel
CO2 emissions
108 g/km
Emission standards
Euro 6
Fuel
95
Mixed driving fuel consumption per 100 km
4.8 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1530 mm
Clearance
135 mm
Curb weight
1485 kg
Front track width
1530 mm
Full weight
1885 kg
Height
1460 mm
Length
4650 mm
Number of doors
5
Wheelbase
2700 mm
Width
1790 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
205/55 R16, 225/45 R17, 225/40 R18
other
Battery type
Lithium-ion (Li-ion)
Body type
Wagon
Car class
C
Flow calculation method
WLTP
Number of seater
5
1.8 CVT (98 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Corolla 12 (E210) [рест.]
2022–2026
98 hp
engine
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Fuel tank capacity
43 l
Injection type
distributed injection (multipoint)
Maximum torque
142 N*m
Min trunk capacity
390 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
fuel
City driving fuel consumption per 100 km
3.6 l
CO2 emissions
79 g/km
Fuel
92
Highway driving fuel consumption per 100 km
3.1 l
Mixed driving fuel consumption per 100 km
3.4 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1530 mm
Clearance
130 mm
Curb weight
1370 kg
Front track width
1530 mm
Full weight
1645 kg
Height
1460 mm
Length
4650 mm
Number of doors
5
Wheelbase
2700 mm
Width
1790 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 205/55 R16, 215/45 R17
other
Battery type
Lithium-ion (Li-ion)
Body type
Wagon
Car class
C
Number of seater
5
1.8 CVT (98 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Noah 4 (R90)
2022–2026
98 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
52 l
Injection type
distributed injection (multipoint)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
fuel
City driving fuel consumption per 100 km
4.4 l
CO2 emissions
100 g/km
Fuel
95
Highway driving fuel consumption per 100 km
4.0 l
Mixed driving fuel consumption per 100 km
4.3 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1515 mm
Clearance
140 mm
Curb weight
1630 kg
Front track width
1500 mm
Full weight
2015 kg
Height
1895 mm
Length
4695 mm
Number of doors
5
Wheelbase
2850 mm
Width
1730 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Right
Wheel size
205/60 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Minivan
Car class
M
Disc size
6x16 ET50
Flow calculation method
WLTP
Number of seater
7, 8
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 CVT 4WD (140 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Corolla 12 (E210) [рест.]
2022–2026
140 hp
engine
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
140 hp
Fuel tank capacity
43 l
Injection type
distributed injection (multipoint)
Max power (kW)
103 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
5200 RPM
performance
Max speed
180 km/h
fuel
Fuel
92
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1549 mm
Clearance
130 mm
Curb weight
1370 kg
Front track width
1532 mm
Full weight
1645 kg
Height
1422 mm
Length
4635 mm
Number of doors
4
Wheelbase
2700 mm
Width
1778 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/45 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Sedan
Car class
C
Number of seater
5
1.8 CVT 4WD (98 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Corolla 12 (E210) [рест.]
2022–2026
98 hp
engine
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Fuel tank capacity
43 l
Injection type
distributed injection (multipoint)
Max trunk capacity
751 l
Maximum torque
142 N*m
Min trunk capacity
325 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
fuel
City driving fuel consumption per 100 km
3.9 l
CO2 emissions
84 g/km
Fuel
92
Highway driving fuel consumption per 100 km
3.3 l
Mixed driving fuel consumption per 100 km
3.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1530 mm
Clearance
130 mm
Curb weight
1420 kg
Front track width
1530 mm
Full weight
1695 kg
Height
1460 mm
Length
4650 mm
Number of doors
5
Wheelbase
2700 mm
Width
1790 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 205/55 R16, 215/45 R17
other
Battery type
Lithium-ion (Li-ion)
Body type
Wagon
Car class
C
Number of seater
5
1.8 CVT 4WD (98 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Noah 4 (R90)
2022–2026
98 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
52 l
Injection type
distributed injection (multipoint)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
fuel
City driving fuel consumption per 100 km
4.5 l
CO2 emissions
106 g/km
Fuel
95
Highway driving fuel consumption per 100 km
4.2 l
Mixed driving fuel consumption per 100 km
4.5 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1515 mm
Clearance
140 mm
Curb weight
1680 kg
Front track width
1500 mm
Full weight
2065 kg
Height
1895 mm
Length
4695 mm
Number of doors
5
Wheelbase
2850 mm
Width
1730 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Right
Wheel size
205/60 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Minivan
Car class
M
Disc size
6x16 ET50
Flow calculation method
WLTP
Number of seater
7, 8
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 CVT (98 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Corolla Cross 1
2020–2025
98 hp
engine
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, longitudinal
Engine power
98 hp
Fuel tank capacity
36 l
Injection type
distributed injection (multipoint)
Max power (kW)
72 kW
Max power at RPM
5800 RPM
Max trunk capacity
487 l
Maximum torque
163 N*m
Min trunk capacity
440 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
8.1 s
fuel
CO2 emissions
98 g/km
Fuel
95
Mixed driving fuel consumption per 100 km
4.3 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1571 mm
Clearance
161 mm
Curb weight
1385 kg
Front track width
1559 mm
Full weight
1655 kg
Height
1620 mm
Length
4460 mm
Number of doors
5
Wheelbase
2640 mm
Width
1825 mm
suspension
Back suspension
Independent, Torsion
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/60 R17, 225/50 R18
other
Battery type
Nickel metal hydride (NiMH)
Body type
Crossover
Car class
C
Disc size
6.5x17 ET45, 7x18 ET50
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 AT (122 hp)
Привід Front wheel drive
КПП Automatic
Levin 12 (E210)
2019–2022
122 hp
engine
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
122 hp
Fuel tank capacity
43 l
Injection type
direct injection (direct)
Max power (kW)
90 kW
Max power at RPM
5200 RPM
Maximum torque
163 N*m
Stroke cycle
88.4 mm
Turnover of maximum torque
3600 RPM
fuel
Fuel
95
Mixed driving fuel consumption per 100 km
4.0 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1535 mm
Curb weight
1410 kg
Front track width
1531 mm
Height
1435 mm
Length
4640 mm
Number of doors
5
Wheelbase
2700 mm
Width
1780 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left
Wheel size
205/55 R16
other
Battery type
Lithium-ion (Li-ion)
Body type
Sedan
Car class
C
Number of seater
5
1.8 AT (98 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
C-HR 1 [рест.]
2019–2024
98 hp
engine
Battery capacity
1.31 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
50 l
Injection type
direct injection (direct)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Min trunk capacity
297 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.0 s
Max speed
170 km/h
fuel
City driving fuel consumption per 100 km
3.5 l
CO2 emissions
86 g/km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
4.3 l
Mixed driving fuel consumption per 100 km
3.9 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
Number of gear
1
dimensions
Back track width
1570 mm
Clearance
160 mm
Curb weight
1420 kg
Front track width
1550 mm
Full weight
1860 kg
Height
1565 mm
Length
4360 mm
Number of doors
5
Wheelbase
2640 mm
Width
1795 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/60 R17, 225/50 R18
other
Battery type
Nickel metal hydride (NiMH)
Body type
Crossover
Car class
B
Disc size
6.5x17 ET45, 7x18 ET50
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 AT (98 hp)
Привід Front wheel drive
КПП Automatic
Prius 4 [рест.] (XW50)
2018–2022
122 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
122 hp
Fuel tank capacity
50 l
Injection type
direct injection (direct)
Max power (kW)
90 kW
Max power at RPM
5200 RPM
Max trunk capacity
1633 l
Maximum torque
142 N*m
Min trunk capacity
501 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
10.6 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
4.4 l
CO2 emissions
70 g/km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
4.1 l
Mixed driving fuel consumption per 100 km
4.2 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1540 mm
Clearance
130 mm
Curb weight
1450 kg
Front track width
1530 mm
Full weight
1790 kg
Height
1470 mm
Length
4540 mm
Number of doors
5
Wheelbase
2700 mm
Width
1760 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 215/45 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Disc size
6.5x15 ET40, 7x17 ET50
Number of seater
5
Pitch Circle Diameter
DIA54.1 5x100 mm
Rating name
EuroNCAP
Safety assessment
5 / 5
1.8 AT 4WD (98 hp)
Привід All wheel drive (AWD)
КПП Automatic
Prius 4 [рест.] (XW50)
2018–2022
122 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
122 hp
Fuel tank capacity
47 l
Injection type
direct injection (direct)
Max power (kW)
90 kW
Max power at RPM
5200 RPM
Max trunk capacity
1633 l
Maximum torque
142 N*m
Min trunk capacity
501 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
10.6 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
4.9 l
CO2 emissions
68 g/km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
4.5 l
Mixed driving fuel consumption per 100 km
4.7 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1540 mm
Clearance
135 mm
Curb weight
1450 kg
Front track width
1530 mm
Height
1470 mm
Length
4540 mm
Number of doors
5
Wheelbase
2700 mm
Width
1760 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 215/45 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Disc size
6.5x15 ET40, 7x17 ET50
Number of seater
5
Pitch Circle Diameter
DIA54.1 5x100 mm
Rating name
EuroNCAP
Safety assessment
5 / 5
1.8 CVT (98 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Corolla 12 (E210)
2018–2026
98 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
Turbocharged
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
43 l
Injection type
distributed injection (multipoint)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Min trunk capacity
380 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.0 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
4.0 l
CO2 emissions
87 g/km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
3.6 l
Mixed driving fuel consumption per 100 km
3.7 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1549 mm
Clearance
130 mm
Curb weight
1420 kg
Front track width
1532 mm
Full weight
1835 kg
Height
1435 mm
Length
4630 mm
Number of doors
4
Wheelbase
2700 mm
Width
1780 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
205/55 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Sedan
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 Hybrid CVT (98 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Corolla 12 (E210)
2018–2026
98 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
50 l
Injection type
distributed injection (multipoint)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Max trunk capacity
313 l
Maximum torque
142 N*m
Min trunk capacity
361 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
10.9 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.4 l
CO2 emissions
68 g/km
Cruising range
from 1 470 to 1 670 km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
3.0 l
Mixed driving fuel consumption per 100 km
3.3 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1530 mm
Clearance
135 mm
Curb weight
1370 kg
Front track width
1530 mm
Full weight
1820 kg
Ground clearance
135 mm
Height
1435 mm
Length
4370 mm
Number of doors
5
Wheelbase
2640 mm
Width
1790 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
other
Battery type
Lithium-ion (Li-ion)
Body type
Hatchback
Car class
C
Front track
1530 mm
Number of seater
5
Rear track
1530 mm
Turning circle
10.6 m
1.8 Hybrid CVT (98 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Corolla 12 (E210)
2018–2026
98 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
43 l
Injection type
distributed injection (multipoint)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Max trunk capacity
751 l
Maximum torque
142 N*m
Min trunk capacity
325 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.1 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
4.0 l
CO2 emissions
87 g/km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
3.6 l
Mixed driving fuel consumption per 100 km
3.7 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1530 mm
Clearance
130 mm
Curb weight
1430 kg
Front track width
1530 mm
Full weight
1835 kg
Ground clearance
135 mm
Height
1435 mm
Length
4653 mm
Number of doors
5
Wheelbase
2700 mm
Width
1790 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
205/55 R16
other
Battery type
Lithium-ion (Li-ion)
Body type
Wagon
Car class
C
Front track
1530 mm
Number of seater
5
Rear track
1530 mm
1.8 CVT (99 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Noah 3 (R80) [рест.]
2017–2021
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
55 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
fuel
City driving fuel consumption per 100 km
5.4 l
CO2 emissions
98 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
5.1 l
Mixed driving fuel consumption per 100 km
5.3 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1480 mm
Clearance
160 mm
Curb weight
1620 kg
Front track width
1500 mm
Full weight
2005 kg
Height
1825 mm
Length
4710 mm
Number of doors
5
Wheelbase
2850 mm
Width
1735 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Right
Wheel size
195/65 R15, 205/55 R16, 205/60 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Minivan
Car class
M
Disc size
6x15 ET50, 6x16 ET50
Number of seater
7, 8
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 CVT (99 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Voxy 3 (R80) [рест.]
2017–2021
2 km
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Electric power reserve
2 km
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
50 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
fuel
City driving fuel consumption per 100 km
5.4 l
CO2 emissions
122 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
5.1 l
Mixed driving fuel consumption per 100 km
5.3 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1480 mm
Clearance
160 mm
Curb weight
1630 kg
Front track width
1500 mm
Full weight
2015 kg
Height
1825 mm
Length
4710 mm
Number of doors
5
Wheelbase
2850 mm
Width
1735 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 205/55 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Minivan
Car class
M
Disc size
6x15 ET50, 6x16 ET50
Number of charging cycles
1500
Number of seater
7, 8
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 Hybrid CVT (99 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Esquire 1 [рест.]
2017–2021
99 hp
engine
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
55 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
fuel
CO2 emissions
98 g/km
Emission standards
Euro 5
Fuel
95
Mixed driving fuel consumption per 100 km
4.2 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1480 mm
Clearance
160 mm
Curb weight
1610 kg
Front track width
1480 mm
Full weight
1995 kg
Ground clearance
160 mm
Height
1825 mm
Length
4695 mm
Number of doors
5
Wheelbase
2850 mm
Width
1695 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15
other
Battery type
Nickel metal hydride (NiMH)
Body type
Minivan
Car class
M
Front track
1480 mm
Number of seater
8
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1480 mm
Turning circle
11 m
1.8 CVT Hybrid (98 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
C-HR 1
2016–2020
98 hp
engine
Battery capacity
1.31 KW⋅h
Boost type
none
Capacity
1798 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
50 l
Injection type
direct injection (direct)
Max power at RPM
to 5 200 RPM
Max trunk capacity
377 l
Maximum torque
142 N*m
Min trunk capacity
297 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.0 s
Max speed
170 km/h
fuel
City driving fuel consumption per 100 km
3.8 l
CO2 emissions
134 g/km
Cruising range
from 1 520 to 1 320 km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
3.3 l
Mixed driving fuel consumption per 100 km
3.6 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1550 mm
Clearance
160 mm
Curb weight
1380 kg
Front track width
1550 mm
Full weight
1860 kg
Ground clearance
148 mm
Height
1565 mm
Length
4360 mm
Number of doors
5
Wheelbase
2640 mm
Width
1795 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/60 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Crossover
Car class
C
Front track
1550 mm
Number of seater
5
Payload
480 kg
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1550 mm
Turning circle
10.4 m
1.8 (136 hp)
Привід Front wheel drive
КПП Automatic
Auris 2 [рест.]
2015–2018
99 hp
engine
Battery capacity
1.31 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
50 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Max trunk capacity
1199 l
Maximum torque
142 N*m
Min trunk capacity
360 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
10.9 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.4 l
CO2 emissions
79 g/km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
3.4 l
Mixed driving fuel consumption per 100 km
3.5 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1525 mm
Clearance
140 mm
Curb weight
1310 kg
Front track width
1535 mm
Full weight
1815 kg
Height
1475 mm
Length
4330 mm
Number of doors
5
Wheelbase
2600 mm
Width
1760 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 205/55 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Disc size
6.5x16 ET45, 6x15 ET39, 7.5x19 ET50, 7x17 ET50
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 (136 hp)
Привід Front wheel drive
КПП Automatic
Auris 2 [рест.]
2015–2018
99 hp
engine
Battery capacity
1.31 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
50 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
4000 RPM
Max trunk capacity
1658 l
Maximum torque
142 N*m
Min trunk capacity
530 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
10.9 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.5 l
CO2 emissions
81 g/km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
3.4 l
Mixed driving fuel consumption per 100 km
3.5 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1525 mm
Clearance
140 mm
Curb weight
1335 kg
Front track width
1535 mm
Full weight
1815 kg
Height
1485 mm
Length
4595 mm
Number of doors
5
Wheelbase
2600 mm
Width
1760 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 205/55 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Wagon
Car class
C
Disc size
6.5x16 ET45, 6x15 ET39, 7.5x19 ET50, 7x17 ET50
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 AT (98 hp)
Привід Front wheel drive
КПП Automatic
Prius 4
2015–2023
45 km
engine
Battery capacity
8.8 KW⋅h
Boost type
none
Capacity
1797 cm3
Electric power reserve
45 km
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
43 l
Injection type
direct injection (direct)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Max trunk capacity
1360 l
Maximum torque
142 N*m
Min trunk capacity
354 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.1 s
Max speed
162 km/h
fuel
City driving fuel consumption per 100 km
4.4 l
CO2 emissions
62 g/km
Consumption
10.0 KW⋅h/100 km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
4.3 l
Mixed driving fuel consumption per 100 km
4.4 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1545 mm
Clearance
130 mm
Curb weight
1605 kg
Front track width
1530 mm
Full weight
1855 kg
Height
1470 mm
Length
4645 mm
Number of doors
5
Wheelbase
2700 mm
Width
1760 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 215/45 R17
other
Battery type
Lithium-ion (Li-ion)
Body type
Hatchback
Car class
C
Charging connector type
Type 2
Charging time
5.5 h
Fast charge time
130 h
Flow calculation method
WLTP
Number of seater
4
Pitch Circle Diameter
DIA54.1 5x100 mm
1.8 AT (98 hp)
Привід Front wheel drive
КПП Automatic
Prius 4
2015–2023
2 km
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Electric power reserve
2 km
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
42 l
Injection type
direct injection (direct)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Max trunk capacity
1633 l
Maximum torque
142 N*m
Min trunk capacity
501 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
10.6 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.1 l
CO2 emissions
70 g/km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
2.9 l
Mixed driving fuel consumption per 100 km
3.0 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1540 mm
Clearance
130 mm
Curb weight
1450 kg
Front track width
1530 mm
Full weight
1790 kg
Height
1470 mm
Length
4540 mm
Number of doors
5
Wheelbase
2700 mm
Width
1760 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 215/45 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Liftback
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA54.1 5x100 mm
1.8 CVT (140 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Corolla 11 (E160, E170, E180) [рест.]
2015–2019
140 hp
engine
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
140 hp
Fuel tank capacity
43 l
Injection type
distributed injection (multipoint)
Max power (kW)
103 kW
Max power at RPM
5200 RPM
Max trunk capacity
1052 l
Maximum torque
142 N*m
Min trunk capacity
361 l
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
9.2 s
Max speed
180 km/h
fuel
CO2 emissions
113 g/km
Emission standards
Euro 6
Fuel
95
Mixed driving fuel consumption per 100 km
5.1 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1530 mm
Clearance
135 mm
Curb weight
1240 kg
Front track width
1530 mm
Full weight
1820 kg
Height
1460 mm
Length
4375 mm
Number of doors
5
Wheelbase
2640 mm
Width
1790 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
205/55 R16, 225/45 R17
other
Battery type
Lithium-ion (Li-ion)
Body type
Hatchback
Car class
C
Flow calculation method
WLTP
Number of seater
5
1.8 AT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius Alpha 1 (ZVW40/41) [рест.]
2014–2021
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Max trunk capacity
1750 l
Maximum torque
142 N*m
Min trunk capacity
232 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.3 s
Max speed
165 km/h
fuel
City driving fuel consumption per 100 km
5.1 l
CO2 emissions
112 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
4.7 l
Mixed driving fuel consumption per 100 km
4.9 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1545 mm
Clearance
145 mm
Curb weight
1380 kg
Front track width
1540 mm
Full weight
1865 kg
Height
1575 mm
Length
4630 mm
Number of doors
5
Wheelbase
2780 mm
Width
1775 mm
suspension
Back suspension
Semi-independent, torsion
Rear brakes
Disc
Steering wheel position
Right
Wheel size
205/60 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Wagon
Car class
M
Number of seater
5, 7
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 AT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius v (+) 1 (Z5W40/41) [рест.]
2014–2021
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Max trunk capacity
1750 l
Maximum torque
142 N*m
Min trunk capacity
232 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.3 s
Max speed
165 km/h
fuel
City driving fuel consumption per 100 km
3.8 l
CO2 emissions
96 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
4.2 l
Mixed driving fuel consumption per 100 km
4.1 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1545 mm
Clearance
145 mm
Curb weight
1495 kg
Front track width
1540 mm
Full weight
2115 kg
Height
1575 mm
Length
4615 mm
Number of doors
5
Wheelbase
2780 mm
Width
1775 mm
suspension
Back suspension
Semi-independent, torsion
Rear brakes
Disc
Steering wheel position
Left
Wheel size
205/60 R16, 215/50 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Wagon
Car class
M
Disc size
6.5x16 ET39, 7x17 ET45
Number of seater
5, 7
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 CVT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius Alpha 1 (ZVW40/41) [рест.]
2014–2021
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Max trunk capacity
1750 l
Maximum torque
142 N*m
Min trunk capacity
232 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.3 s
Max speed
165 km/h
fuel
City driving fuel consumption per 100 km
5.1 l
CO2 emissions
112 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
4.7 l
Mixed driving fuel consumption per 100 km
4.9 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1545 mm
Clearance
145 mm
Curb weight
1380 kg
Front track width
1540 mm
Full weight
1865 kg
Height
1575 mm
Length
4630 mm
Number of doors
5
Wheelbase
2780 mm
Width
1775 mm
suspension
Back suspension
Semi-independent, torsion
Rear brakes
Disc
Steering wheel position
Right
Wheel size
205/60 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Wagon
Car class
M
Disc size
6.5x16 ET39, 7x17 ET45
Number of seater
5, 7
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 CVT (99 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Esquire 1
2014–2017
99 hp
engine
Boost type
none
Capacity
1797 cm3
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
55 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
fuel
CO2 emissions
98 g/km
Emission standards
Euro 5
Fuel
95
Mixed driving fuel consumption per 100 km
4.2 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1475 mm
Clearance
160 mm
Curb weight
1610 kg
Front track width
1480 mm
Full weight
1995 kg
Height
1825 mm
Length
4695 mm
Number of doors
5
Wheelbase
2825 mm
Width
1695 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15
other
Battery type
Nickel metal hydride (NiMH)
Body type
Minivan
Car class
M
Number of seater
8
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 CVT Hybrid (99 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Voxy 3
2014–2017
2 km
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Electric power reserve
2 km
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
50 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
fuel
CO2 emissions
98 g/km
Emission standards
Euro 5
Fuel
95
Mixed driving fuel consumption per 100 km
4.2 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1480 mm
Clearance
160 mm
Curb weight
1620 kg
Front track width
1500 mm
Full weight
2005 kg
Ground clearance
160 mm
Height
1825 mm
Length
4710 mm
Number of doors
5
Wheelbase
2825 mm
Width
1730 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 205/55 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Minivan
Car class
M
Front track
1500 mm
Number of charging cycles
1500
Number of seater
7, 8
Payload
385 kg
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1480 mm
1.8 Hybrid CVT (99 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Noah 3
2014–2017
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
55 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
fuel
City driving fuel consumption per 100 km
5.4 l
CO2 emissions
98 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
5.1 l
Mixed driving fuel consumption per 100 km
5.3 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1475 mm
Clearance
160 mm
Curb weight
1620 kg
Front track width
1480 mm
Full weight
2005 kg
Ground clearance
160 mm
Height
1825 mm
Length
4695 mm
Number of doors
5
Wheelbase
2825 mm
Width
1695 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Right
Wheel size
195/65 R15, 205/55 R16, 205/60 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Minivan
Car class
M
Front track
1480 mm
Number of seater
7, 8
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1480 mm
Turning circle
11 m
1.8 AT (99 hp)
Привід Front wheel drive
КПП Automatic
Auris 2
2012–2015
2 km
engine
Boost type
none
Capacity
1798 cm3
Electric power reserve
2 km
Engine model
2ZR-FXE
Engine placement
Front, transverse
Fuel tank capacity
50 l
Injection type
distributed injection (multipoint)
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
10.9 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.9 l
CO2 emissions
91 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
3.6 l
Mixed driving fuel consumption per 100 km
3.8 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1525 mm
Clearance
140 mm
Curb weight
1385 kg
Front track width
1535 mm
Full weight
1815 kg
Height
1460 mm
Length
4275 mm
Number of doors
5
Wheelbase
2600 mm
Width
1760 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 AT (99 hp)
Привід Front wheel drive
КПП Automatic
Auris 2
2012–2015
2 km
engine
Boost type
none
Capacity
1797 cm3
Electric power reserve
2 km
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
50 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Max trunk capacity
1658 l
Maximum torque
142 N*m
Min trunk capacity
530 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
3.9 l
CO2 emissions
91 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
3.7 l
Mixed driving fuel consumption per 100 km
3.9 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1520 mm
Clearance
140 mm
Curb weight
1420 kg
Front track width
1525 mm
Full weight
1815 kg
Height
1475 mm
Length
4560 mm
Number of doors
5
Wheelbase
2600 mm
Width
1760 mm
suspension
Back suspension
Independent, spring
Rear brakes
Disc
Steering wheel position
Left
Wheel size
195/65 R15
other
Battery type
Nickel metal hydride (NiMH)
Body type
Wagon
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 AT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius 3 [рест.]
2011–2016
23 km
engine
Battery capacity
4.4 KW⋅h
Boost type
none
Capacity
1797 cm3
Electric power reserve
23 km
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Min trunk capacity
445 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
10.8 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.9 l
Consumption
5.2 KW⋅h/100 km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
3.7 l
Mixed driving fuel consumption per 100 km
3.9 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1520 mm
Clearance
140 mm
Curb weight
1495 kg
Front track width
1525 mm
Full weight
1805 kg
Height
1490 mm
Length
4480 mm
Number of doors
5
Wheelbase
2700 mm
Width
1745 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15
other
Battery type
Lithium-ion (Li-ion)
Body type
Hatchback
Car class
C
Charging connector type
Type 1
Charging time
1.5 h
Disc size
6x15 ET45
Number of seater
5
Pitch Circle Diameter
DIA54.1 5x100 mm
1.8 AT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius 3 [рест.]
2011–2016
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Min trunk capacity
445 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
10.4 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.9 l
CO2 emissions
89 g/km
Emission standards
Euro 4
Fuel
95
Highway driving fuel consumption per 100 km
3.7 l
Mixed driving fuel consumption per 100 km
3.9 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1520 mm
Clearance
140 mm
Curb weight
1445 kg
Front track width
1525 mm
Full weight
1805 kg
Height
1490 mm
Length
4480 mm
Number of doors
5
Wheelbase
2700 mm
Width
1745 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA54.1 5x100 mm
1.8 AT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius v (+) ZVW40
2011–2014
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Max trunk capacity
1750 l
Maximum torque
142 N*m
Min trunk capacity
232 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.3 s
Max speed
165 km/h
fuel
City driving fuel consumption per 100 km
3.8 l
CO2 emissions
96 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
4.2 l
Mixed driving fuel consumption per 100 km
4.1 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1545 mm
Clearance
145 mm
Curb weight
1495 kg
Front track width
1540 mm
Full weight
2115 kg
Height
1575 mm
Length
4615 mm
Number of doors
5
Wheelbase
2780 mm
Width
1775 mm
suspension
Back suspension
Semi-independent, torsion
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
205/60 R16, 215/50 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Wagon
Car class
M
Disc size
6.5x16 ET39, 7x17 ET45
Number of seater
5, 7
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 AT (99 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Prius Alpha 1 (ZVW40/41)
2011–2014
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Max trunk capacity
1750 l
Maximum torque
142 N*m
Min trunk capacity
232 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.3 s
Max speed
165 km/h
fuel
Fuel
95
Mixed driving fuel consumption per 100 km
2.6 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
Number of gear
1
dimensions
Back track width
1545 mm
Clearance
145 mm
Curb weight
1480 kg
Front track width
1540 mm
Full weight
1865 kg
Height
1575 mm
Length
4615 mm
Number of doors
5
Wheelbase
2780 mm
Width
1775 mm
suspension
Back suspension
Semi-independent, torsion
Rear brakes
Disc
Steering wheel position
Right
Wheel size
205/60 R16, 215/50 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Wagon
Car class
M
Number of seater
5, 7
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 CVT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius Alpha 1 (ZVW40/41)
2011–2014
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Max trunk capacity
1750 l
Maximum torque
142 N*m
Min trunk capacity
232 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.3 s
Max speed
165 km/h
fuel
Fuel
95
Mixed driving fuel consumption per 100 km
2.6 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1545 mm
Clearance
145 mm
Curb weight
1480 kg
Front track width
1540 mm
Full weight
1865 kg
Height
1575 mm
Length
4615 mm
Number of doors
5
Wheelbase
2780 mm
Width
1775 mm
suspension
Back suspension
Semi-independent, torsion
Rear brakes
Disc
Steering wheel position
Right
Wheel size
205/60 R16, 215/50 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Wagon
Car class
M
Disc size
6.5x16 ET39, 7x17 ET45
Number of seater
5, 7
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Plug-in Hybrid 1.8hyb AT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius 3 [рест.]
2012–2015
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Min trunk capacity
445 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
10.4 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.9 l
CO2 emissions
89 g/km
Emission standards
Euro 4
Fuel
95
Highway driving fuel consumption per 100 km
3.7 l
Mixed driving fuel consumption per 100 km
3.9 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1520 mm
Clearance
140 mm
Curb weight
1445 kg
Front track width
1525 mm
Full weight
1805 kg
Height
1490 mm
Length
4480 mm
Number of doors
5
Wheelbase
2700 mm
Width
1745 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA54.1 5x100 mm
1.8 AT (98 hp)
Привід Front wheel drive
КПП Automatic
Auris 1 [рест.]
2009–2012
98 hp
engine
Boost type
none
Capacity
1798 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Fuel tank capacity
55 l
Injection type
distributed injection (multipoint)
Maximum torque
142 N*m
Min trunk capacity
350 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.4 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
4.0 l
CO2 emissions
93 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
4.0 l
Mixed driving fuel consumption per 100 km
4.0 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1525 mm
Clearance
114 mm
Curb weight
1455 kg
Front track width
1525 mm
Full weight
1805 kg
Height
1515 mm
Length
4245 mm
Number of doors
5
Wheelbase
2600 mm
Width
1760 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
1.8 AT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius 3
2009–2011
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Min trunk capacity
445 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
10.4 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.9 l
CO2 emissions
89 g/km
Emission standards
Euro 4
Fuel
95
Highway driving fuel consumption per 100 km
3.7 l
Mixed driving fuel consumption per 100 km
3.9 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1520 mm
Clearance
140 mm
Curb weight
1445 kg
Front track width
1525 mm
Full weight
1805 kg
Height
1500 mm
Length
4460 mm
Number of doors
5
Wheelbase
2700 mm
Width
1745 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 215/45 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA54.1 5x100 mm
1.8hyb AT (99 hp)
Привід Front wheel drive
КПП Automatic
Prius 3
2009–2011
99 hp
engine
Battery capacity
1.3 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
99 hp
Fuel tank capacity
45 l
Injection type
distributed injection (multipoint)
Max power (kW)
73 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Min trunk capacity
445 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
10.4 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
3.9 l
CO2 emissions
89 g/km
Emission standards
Euro 4
Fuel
95
Highway driving fuel consumption per 100 km
3.7 l
Mixed driving fuel consumption per 100 km
3.9 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1520 mm
Clearance
140 mm
Curb weight
1445 kg
Front track width
1525 mm
Full weight
1805 kg
Height
1500 mm
Length
4460 mm
Number of doors
5
Wheelbase
2700 mm
Width
1745 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
195/65 R15, 215/45 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA54.1 5x100 mm
1.8 CVT (98 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Voxy 2
2007–2010
98 hp
engine
Battery capacity
0.9 KW⋅h
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
52 l
Injection type
distributed injection (multipoint)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Maximum torque
142 N*m
Stroke cycle
88.3 mm
Turnover of maximum torque
3600 RPM
fuel
City driving fuel consumption per 100 km
4.5 l
CO2 emissions
106 g/km
Emission standards
Euro 6
Fuel
95
Highway driving fuel consumption per 100 km
4.2 l
Mixed driving fuel consumption per 100 km
4.5 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1515 mm
Clearance
125 mm
Curb weight
1690 kg
Front track width
1500 mm
Full weight
2075 kg
Height
1895 mm
Length
4695 mm
Number of doors
5
Wheelbase
2850 mm
Width
1730 mm
suspension
Back suspension
Semi-dependent, spring
Rear brakes
ventilated disc
Steering wheel position
Right
Wheel size
205/60 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Minivan
Car class
M
Number of seater
7, 8
1.8 AT (98 hp)
Привід Front wheel drive
КПП Automatic
Auris 1
2006–2010
98 hp
engine
Boost type
none
Capacity
1797 cm3
Engine model
2ZR-FXE
Engine placement
Front, transverse
Engine power
98 hp
Fuel tank capacity
55 l
Injection type
distributed injection (multipoint)
Max power (kW)
72 kW
Max power at RPM
5200 RPM
Max trunk capacity
761 l
Maximum torque
142 N*m
Min trunk capacity
354 l
Stroke cycle
88.3 mm
Turnover of maximum torque
4000 RPM
performance
Acceleration (0-100 km/h)
11.4 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
4.0 l
CO2 emissions
93 g/km
Emission standards
Euro 5
Fuel
95
Highway driving fuel consumption per 100 km
4.0 l
Mixed driving fuel consumption per 100 km
4.0 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
1
dimensions
Back track width
1533 mm
Clearance
114 mm
Curb weight
1455 kg
Front track width
1536 mm
Full weight
1805 kg
Height
1515 mm
Length
4220 mm
Number of doors
5
Wheelbase
2600 mm
Width
1760 mm
suspension
Back suspension
Semi-independent, torsion
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
205/55 R16
other
Battery type
Nickel metal hydride (NiMH)
Body type
Hatchback
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Cars with the 2ZR-FXE engine
This engine was fitted to 9 models
| Photo | Brand | Model | Generation | Production years |
|---|---|---|---|---|
|
No photo
|
Lexus | CT | CT | 2010 - 2022 |
|
Toyota | Auris | Auris | 2007 - 2012 |
|
Toyota | Auris | Auris II (E180) | 2012 - 2018 |
|
Toyota | Avensis | Avensis III (T270) | 2009 - 2018 |
|
No photo
|
Toyota | Corolla | Corolla X (E140) | 2006 - 2013 |
|
No photo
|
Toyota | Corolla | Corolla X (E150) | 2006 - 2013 |
|
No photo
|
Toyota | Corolla | Corolla XI (E170) (US) | 2012 - present |
|
No photo
|
Toyota | Corolla | Corolla XI (E170) | 2012 - present |
|
No photo
|
Toyota | Ist | ist II | 2007 - 2016 |
|
Toyota | Mirai | Mirai | 2014 - 2020 |
|
Toyota | Prius | Prius | 2003 - 2009 |
|
Toyota | Prius | Prius III (XW30) | 2009 - 2015 |
|
Toyota | Prius | Prius IV (XW50) | 2015 - present |
|
Toyota | Verso | Verso | 2009 - present |
|
No photo
|
Toyota | Wish | Wish II | 2009 - 2017 |
All modifications (27)
| Vehicle | Generation | Modification | Power | Gearbox | Drive |
|---|---|---|---|---|---|
| Lexus CT | CT | 1.8 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
| Lexus CT | CT | 2.0 150 л.с. 6-МКП 2WD | 150 hp | 6-МКП | 2WD |
| Lexus CT | CT | 2.0 150 л.с. CVT 2WD | 150 hp | CVT | 2WD |
| Lexus CT | CT | 2.0 200 л.с. 6-МКП 2WD | 200 hp | 6-МКП | 2WD |
| Lexus CT | CT | 2.0 200 л.с. CVT 2WD | 200 hp | CVT | 2WD |
| Toyota Auris | Auris | 1.8 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
| Toyota Auris | Auris II (E180) | 1.8 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
| Toyota Auris | Auris II (E180) | 1.8 Hybrid 136 л.с. CVT 4x4 | 136 hp | CVT | 4x4 |
| Toyota Avensis | Avensis III (T270) | 2.0 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
| Toyota Avensis | Avensis III (T270) | 2.0 Hybrid 136 л.с. CVT 4x4 | 136 hp | CVT | 4x4 |
| Toyota Corolla | Corolla X (E140) | 1.8 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
| Toyota Corolla | Corolla X (E150) | 1.8 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
| Toyota Corolla | Corolla XI (E170) (US) | 1.8L Hybrid 134 hp eCVT 2WD | 134 hp | eCVT | 2WD |
| Toyota Corolla | Corolla XI (E170) | 1.8 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
| Toyota Ist | ist II | 1.8 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
| Toyota Mirai | Mirai | Toyota Mirai 114 к.с. 1-електродвигун 1-автомат 2WD | 114 hp | 1-автомат | 2WD |
| Toyota Mirai | Mirai | Toyota Mirai 114 к.с. 1-електродвигун 1-автомат 4x4 | 114 hp | 1-автомат | 4x4 |
| Toyota Prius | Prius | 1.8 Hybrid 98 л.с. CVT 2WD | 98 hp | CVT | 2WD |
| Toyota Prius | Prius | 1.8 Hybrid 98 л.с. CVT 4x4 | 98 hp | CVT | 4x4 |
| Toyota Prius | Prius III (XW30) | 1.8 Hybrid 98 л.с. CVT 2WD | 98 hp | CVT | 2WD |
| Toyota Prius | Prius III (XW30) | 1.8 Hybrid 98 л.с. CVT 4x4 | 98 hp | CVT | 4x4 |
| Toyota Prius | Prius III (XW30) | 1.8 Hybrid 134 л.с. CVT 2WD | 134 hp | CVT | 2WD |
| Toyota Prius | Prius III (XW30) | 1.8 Hybrid 134 л.с. CVT 4x4 | 134 hp | CVT | 4x4 |
| Toyota Prius | Prius IV (XW50) | 1.8 Hybrid 122 л.с. CVT 2WD | 122 hp | CVT | 2WD |
| Toyota Prius | Prius IV (XW50) | 1.8 Hybrid 122 л.с. CVT 4x4 | 122 hp | CVT | 4x4 |
| Toyota Verso | Verso | 2.0 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
| Toyota Wish | Wish II | 1.8 Hybrid 136 л.с. CVT 2WD | 136 hp | CVT | 2WD |
Interesting Facts
- The 2ZR-FXE is known for its fuel efficiency and low emissions.
- It features Toyota's Dual VVT-i technology for improved performance.
- Used in both hybrid and non-hybrid applications.
Applications
Total produced: over 1000000
| Vehicle | Generation | Years | Power | Markets |
|---|---|---|---|---|
| Toyota Prius | ZVW30 | 2009-2015 | 100hp | Global |
| Toyota Corolla | E160 | 2012-2019 | 100hp | Global |
Compatible transmissions: CVT, 6-speed Manual
Drive types: FWD
Fuel Economy
| Fuel Type | Petrol 95 |
| Octane Rating | Minimum: 91 | Recommended: 95 |
| Consumption (City) | 5.5 L/100km |
| Consumption (Highway) | 4.5 L/100km |
| Consumption (Combined) | 5 L/100km |
| Real Consumption | 5.2 L/100km |
| Fuel Tank Capacity | 50 L |
| Range | 1,000 km |
| Cost per 100 km | 8-10 USD |
Emissions Standards
| Emission Standard | Euro 5 |
| CO₂ Emissions | 120 g/km |
| Particulate Filter (DPF) | Absent |
| AdBlue | Not Required |
Awards and Recognition
- Best Engine (2011) — Hybrid
Comparison with competitors
| Engine | Brand | Displacement | Power | Torque |
|---|---|---|---|---|
| K14B | Suzuki | 1,400 cc | 95 hp | 130 Nm |
| 1.5L K-Series | Honda | 1,497 cc | 100 hp | 130 Nm |
Pros
- Excellent fuel economy
- Reliable and durable
- Low maintenance costs
Cons
- Limited tuning potential
- Some issues with oil consumption in early models
