2AR-FE Toyota 2AR-FE
2AR-FE - це надійний 2.4-літровий атмосферний двигун з електронним впорском пального, що забезпечує хорошу продуктивність і економічність.
74
Двигунів бренду
30
Модифікацій
Technical Specifications
| Engine Displacement | 2.0 л (1,998 см³) |
| Configuration | Inline-4 |
| Number of Cylinders | 4 |
| Valves per Cylinder | 4 |
| Power | 147 - 158 л.с. |
| Torque | 180 - 200 Н*м |
| Cylinder Bore | 87.50 мм |
| Piston Stroke | 102.00 мм |
| Compression Ratio | 10.4:1 |
| Firing Order | 1-3-4-2 |
| Fuel System | Dual VVT-i |
| Aspiration | Naturally Aspirated |
| Intercooler | No |
| Maximum RPM | 6,000 об/хв |
| Max Torque RPM | 4,400 об/хв |
| Valve Train | DOHC |
| Timing Drive | Chain |
| Timing Chain Replacement | 200000 or as needed |
| Block Material | Aluminum |
| Head Material | Aluminum |
| Engine Weight | 130 кг |
| Dimensions (L×W×H) | 600 × 500 × 600 мм |
| Lubrication System | Wet sump |
| Cooling System | Liquid cooling |
Additional Information
| Engine Family | AR engine family |
| Manufacturing Plant | Takaoka, Japan |
| Predecessor | 1AZ-FE |
Maintenance
| Engine Oil Capacity | 4.5 л (з фільтром: 4.8 л) |
| Recommended Viscosity | 0W-20 |
| Oil Standard | API SN, ILSAC GF-5 |
| Recommended Brands | Toyota Genuine Oil, Mobil 1, Castrol Edge |
| Oil Change Interval | 10 000 км або 12 міс. |
| Oil Filter | 90915-YZZD3 |
| Air Filter |
17801-0T020
Заміна кожні 30 000 км |
| Cabin Filter | 87139-0E010 |
| Spark Plugs |
Тип: Iridium Артикул: 90919-17250Зазор: 1.1 мм Кількість: 4 шт Заміна кожні 100 000 км |
| Coolant Capacity | 6 л |
| Coolant Type | Toyota Super Long Life Coolant (Toyota) |
| Coolant Change Interval | 160 000 км |
| Thermostat Opening Temperature | 82°C |
| Operating Temperature | 90°C |
| Max Operating Temperature | 110°C |
| Critical Temperature | 120°C |
| Annual Maintenance Cost | 500-800 USD |
Надійність
Очікуваний ресурс: 300 000 км
Типові проблеми
| Проблема | Серйозність | Пробіг | Вартість ремонту |
|---|---|---|---|
| Oil consumption issues | Medium | 100000-150000 km | $300-600 |
| VVT-i actuator failure | Medium | 120000-180000 km | $500-800 |
Відомі дефекти
- Some early models had oil consumption issues
- VVT-i actuator problems
Розширення гарантії
- Toyota extended warranty for engine issues up to 5 years/100000 miles
Потенціал тюнінгу
Потенціал тюнінгу: Medium | Макс. безпечна потужність: 250 л.с.
| Етап | Потужність | Крутний момент | Метод | Вартість |
|---|---|---|---|---|
| Stage 1 | 170 л.с. | 210 Н*м |
ECU remap only Вплив на надійність: Minimal |
$400 |
| Stage 2 | 190 л.с. | 230 Н*м |
- Необхідно: Cold air intake, ECU remap Вплив на надійність: Low |
$1200 |
| Stage 3 | 220 л.с. | 250 Н*м |
- Необхідно: Turbocharger kit, ECU remap Вплив на надійність: Medium |
$3000 |
Популярні модифікації
- ECU tune
- Cold air intake
- Exhaust system upgrade
Обмеження тюнінгу
- Stock internals limit power
- Turbocharging requires significant modifications
Детальні технічні характеристики
27
модифікацій
173–321
к.с.
Спільні характеристики
| Back suspension | Independent, spring |
| Boost type | none |
| Country | Japan |
| Cylinder layout | inline |
| Front suspension | Independent, spring |
| Fuel | 95 |
| Number of cylinders | 4 |
| Timing belt | DOHC |
| Valves per cylinder | 4 |
Модифікації двигуна
2.5 CVT 4WD (182 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Alphard 4
2023–2026
182 hp
engine
Capacity
2493 cm3
Compression ratio
10.8
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
182 hp
Engine type
Gasoline
Fuel tank capacity
75 l
Injection type
distributed injection (multipoint)
Max power (kW)
134 kW
Max power at RPM
6000 RPM
Maximum torque
235 N*m
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
fuel
City driving fuel consumption per 100 km
13.9 l
CO2 emissions
213 g/km
Highway driving fuel consumption per 100 km
7.9 l
Mixed driving fuel consumption per 100 km
9.4 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1600 mm
Clearance
150 mm
Curb weight
2060 kg
Front track width
1600 mm
Full weight
2445 kg
Height
1935 mm
Length
4995 mm
Number of doors
5
Wheelbase
3000 mm
Width
1850 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
225/60 R18
other
Body type
Minivan
Car class
M
Number of seater
7
2.5 AT (181 hp)
Привід Front wheel drive
КПП Automatic
Camry 7 (XV50) [2th restyling]
2017–2018
181 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine placement
Front, transverse
Engine power
181 hp
Engine type
Gasoline
Fuel tank capacity
70 l
Injection type
distributed injection (multipoint)
Max power (kW)
133 kW
Max power at RPM
6000 RPM
Maximum torque
231 N*m
Min trunk capacity
506 l
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
9.0 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
11.0 l
CO2 emissions
183 g/km
Emission standards
Euro 4
Highway driving fuel consumption per 100 km
5.9 l
Mixed driving fuel consumption per 100 km
7.8 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1565 mm
Clearance
160 mm
Curb weight
1540 kg
Front track width
1575 mm
Full weight
2100 kg
Height
1480 mm
Length
4850 mm
Number of doors
4
Wheelbase
2775 mm
Width
1825 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left
Wheel size
215/55 R17, 215/60 R16
other
Body type
Sedan
Car class
E
Disc size
6.5x16 ET45, 7x17 ET45
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT (181 hp)
Привід Front wheel drive
КПП Automatic
Camry 8 (XV70)
2017–2021
181 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
181 hp
Engine type
Gasoline
Fuel tank capacity
60 l
Injection type
distributed injection (multipoint)
Max power (kW)
133 kW
Max power at RPM
6000 RPM
Max trunk capacity
428 l
Maximum torque
231 N*m
Min trunk capacity
400 l
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
9.9 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
11.5 l
CO2 emissions
183 g/km
Cruising range
from 520 to 940 km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.4 l
Mixed driving fuel consumption per 100 km
8.3 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1605 mm
Clearance
155 mm
Curb weight
1555 kg
Front track width
1600 mm
Full weight
2100 kg
Ground clearance
155 mm
Height
1445 mm
Length
4879 mm
Number of doors
4
Wheelbase
2825 mm
Width
1839 mm
suspension
Front brakes
Disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/55 R17, 215/60 R16
other
Body type
Sedan
Car class
D
Front track
1580 mm
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1600 mm
Turning circle
11.4 m
2.5 CVT (182 hp)
Привід Front wheel drive
КПП Continuously variable transmission (CVT)
Vellfire 2 [рест.]
2017–2023
182 hp
engine
Capacity
2494 cm3
Compression ratio
10.8
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
182 hp
Engine type
Gasoline
Fuel tank capacity
65 l
Injection type
distributed injection (multipoint)
Max power (kW)
134 kW
Max power at RPM
6000 RPM
Maximum torque
235 N*m
Stroke cycle
98 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
11.3 s
Max speed
170 km/h
fuel
Emission standards
Euro 5
Mixed driving fuel consumption per 100 km
8.6 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1595 mm
Clearance
160 mm
Curb weight
1950 kg
Front track width
1600 mm
Full weight
2390 kg
Height
1950 mm
Length
4935 mm
Number of doors
5
Wheelbase
3000 mm
Width
1850 mm
suspension
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
215/65 R16
other
Body type
Minivan
Car class
M
Disc size
6.5x16 ET33, 6.5x17 ET33, 7.5x18 ET45
Number of seater
7
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 CVT 4WD (182 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Vellfire 2 [рест.]
2017–2023
182 hp
engine
Capacity
2494 cm3
Compression ratio
10.8
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
182 hp
Engine type
Gasoline
Fuel tank capacity
65 l
Injection type
distributed injection (multipoint)
Max power (kW)
134 kW
Max power at RPM
6000 RPM
Maximum torque
235 N*m
Stroke cycle
98 mm
Turnover of maximum torque
4100 RPM
fuel
Emission standards
Euro 5
Mixed driving fuel consumption per 100 km
8.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1595 mm
Clearance
160 mm
Curb weight
2050 kg
Front track width
1600 mm
Full weight
2435 kg
Height
1950 mm
Length
4935 mm
Number of doors
5
Wheelbase
3000 mm
Width
1850 mm
suspension
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
215/65 R16
other
Body type
Minivan
Car class
M
Disc size
6.5x16 ET33, 6.5x17 ET33, 7.5x18 ET45
Number of seater
7
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 CVT AWD (182 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Alphard 3 [рест.]
2017–2023
182 hp
engine
Capacity
2493 cm3
Compression ratio
10.8
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
182 hp
Engine type
Gasoline
Fuel tank capacity
65 l
Injection type
direct injection (direct)
Max power at RPM
to 6 000 RPM
Maximum torque
235 N*m
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
11.3 s
Max speed
170 km/h
fuel
City driving fuel consumption per 100 km
12.8 l
CO2 emissions
200 g/km
Highway driving fuel consumption per 100 km
8.3 l
Mixed driving fuel consumption per 100 km
9.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1600 mm
Clearance
160 mm
Curb weight
1990 kg
Front track width
1625 mm
Full weight
2375 kg
Ground clearance
160 mm
Height
1945 mm
Length
4945 mm
Number of doors
5
Wheelbase
3000 mm
Width
1850 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/65 R16
other
Body type
Minivan
Car class
M
Front track
1600 mm
Number of seater
7, 8
Payload
415 kg
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1605 mm
Turning circle
11.2 m
2.5 AT (179 hp)
Привід Front wheel drive
КПП Automatic
RAV4 4 (XA40) [рест.]
2015–2019
179 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
179 hp
Engine type
Gasoline
Fuel tank capacity
60 l
Injection type
distributed injection (multipoint)
Max power (kW)
131 kW
Max power at RPM
6000 RPM
Maximum torque
233 N*m
Min trunk capacity
577 l
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
fuel
City driving fuel consumption per 100 km
10.2 l
Highway driving fuel consumption per 100 km
7.8 l
Mixed driving fuel consumption per 100 km
9.0 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1570 mm
Clearance
155 mm
Curb weight
1569 kg
Front track width
1570 mm
Full weight
2054 kg
Height
1670 mm
Length
4605 mm
Number of doors
5
Wheelbase
2660 mm
Width
1845 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left
Wheel size
225/65 R17
other
Body type
Crossover
Car class
C
Disc size
6.5x17 ET39, 7.5x18 ET45, 7x17 ET39
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT 4WD (180 hp)
Привід All wheel drive (AWD)
КПП Automatic
RAV4 4 (XA40) [рест.]
2015–2019
180 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
180 hp
Engine type
Gasoline
Fuel tank capacity
60 l
Injection type
distributed injection (multipoint)
Max power (kW)
132 kW
Max power at RPM
6000 RPM
Maximum torque
233 N*m
Min trunk capacity
577 l
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
9.4 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
11.6 l
CO2 emissions
200 g/km
Emission standards
Euro 5
Highway driving fuel consumption per 100 km
6.9 l
Mixed driving fuel consumption per 100 km
8.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1570 mm
Clearance
165 mm
Curb weight
1685 kg
Front track width
1570 mm
Full weight
2130 kg
Height
1670 mm
Length
4605 mm
Number of doors
5
Wheelbase
2660 mm
Width
1845 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left
Wheel size
225/65 R17
other
Body type
Crossover
Car class
C
Disc size
6.5x17 ET39, 7.5x18 ET45, 7x17 ET39
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 CVT 4WD (182 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Vellfire 2
2015–2017
182 hp
engine
Capacity
2494 cm3
Compression ratio
10.8
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
182 hp
Engine type
Gasoline
Fuel tank capacity
65 l
Injection type
distributed injection (multipoint)
Max power (kW)
134 kW
Max power at RPM
6000 RPM
Maximum torque
235 N*m
Stroke cycle
98 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
11.3 s
Max speed
170 km/h
fuel
Emission standards
Euro 5
Mixed driving fuel consumption per 100 km
8.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1595 mm
Clearance
160 mm
Curb weight
2050 kg
Front track width
1600 mm
Full weight
2435 kg
Ground clearance
170 mm
Height
1950 mm
Length
4930 mm
Number of doors
5
Wheelbase
3000 mm
Width
1850 mm
suspension
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
215/65 R16
other
Body type
Minivan
Car class
M
Front track
1600 mm
Number of seater
7
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1595 mm
Turning circle
11.6 m
2.5 CVT AWD (182 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Alphard 3
2015–2017
182 hp
engine
Capacity
2493 cm3
Compression ratio
10.8
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
182 hp
Engine type
Gasoline
Fuel tank capacity
75 l
Injection type
distributed injection (multipoint)
Max power at RPM
to 6 000 RPM
Maximum torque
235 N*m
Min trunk capacity
1900 l
Stroke cycle
98 mm
Turnover of maximum torque
4100 RPM
fuel
Emission standards
Euro 5
Mixed driving fuel consumption per 100 km
8.3 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1625 mm
Clearance
160 mm
Curb weight
2050 kg
Front track width
1600 mm
Full weight
2435 kg
Ground clearance
170 mm
Height
1895 mm
Length
4915 mm
Number of doors
5
Wheelbase
3000 mm
Width
1850 mm
suspension
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
215/65 R16
other
Body type
Minivan
Car class
M
Front track
1600 mm
Number of seater
4, 7, 8
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1595 mm
Turning circle
11.6 m
2.5 AT (181 hp)
Привід Front wheel drive
КПП Automatic
Zelas 1 [рест.]
2013–2016
181 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
181 hp
Engine type
Gasoline
Fuel tank capacity
55 l
Injection type
direct injection (direct)
Max power (kW)
133 kW
Max power at RPM
6000 RPM
Maximum torque
233 N*m
Min trunk capacity
416 l
Stroke cycle
98 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
7.4 s
Max speed
190 km/h
fuel
City driving fuel consumption per 100 km
10.0 l
Highway driving fuel consumption per 100 km
7.6 l
Mixed driving fuel consumption per 100 km
9.0 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1560 mm
Clearance
160 mm
Curb weight
1400 kg
Front track width
1539 mm
Height
1415 mm
Length
4420 mm
Number of doors
2
Wheelbase
2700 mm
Width
1796 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left
Wheel size
215/50 R17
other
Body type
Coupe
Car class
C
Disc size
7.5x18 ET39, 7x17 ET45
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT (176 hp)
Привід Front wheel drive
КПП Automatic
RAV4 4 (XA40)
2012–2015
176 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, transverse
Engine power
176 hp
Engine type
Gasoline
Fuel tank capacity
60 l
Injection type
distributed injection (multipoint)
Max power (kW)
129 kW
Max power at RPM
6000 RPM
Max trunk capacity
1705 l
Maximum torque
233 N*m
Min trunk capacity
506 l
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
fuel
City driving fuel consumption per 100 km
9.8 l
Highway driving fuel consumption per 100 km
7.6 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1570 mm
Clearance
160 mm
Curb weight
1558 kg
Front track width
1570 mm
Full weight
2034 kg
Height
1670 mm
Length
4570 mm
Number of doors
5
Wheelbase
2660 mm
Width
1845 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left
Wheel size
225/65 R17
other
Body type
Crossover
Car class
C
Disc size
6.5x17 ET39, 7.5x18 ET45, 7x17 ET39
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rating name
EuroNCAP
Safety assessment
5 / 5
2.5 AT 4WD (179 hp)
Привід All wheel drive (AWD)
КПП Automatic
RAV4 4 (XA40)
2012–2015
179 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, transverse
Engine power
179 hp
Engine type
Gasoline
Fuel tank capacity
60 l
Injection type
distributed injection (multipoint)
Max power (kW)
132 kW
Max power at RPM
6000 RPM
Max trunk capacity
1705 l
Maximum torque
233 N*m
Min trunk capacity
506 l
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
9.4 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
11.4 l
Highway driving fuel consumption per 100 km
6.8 l
Mixed driving fuel consumption per 100 km
8.5 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1570 mm
Clearance
165 mm
Curb weight
1685 kg
Front track width
1570 mm
Full weight
2130 kg
Height
1670 mm
Length
4570 mm
Number of doors
5
Wheelbase
2660 mm
Width
1845 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left
Wheel size
225/65 R17
other
Body type
Crossover
Car class
C
Disc size
6.5x17 ET39, 7.5x18 ET45, 7x17 ET39
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rating name
EuroNCAP
Safety assessment
5 / 5
2.5 CVT (321 hp)
Привід All wheel drive (AWD)
КПП Continuously variable transmission (CVT)
Crown S210
2012–2015
321 hp
engine
Capacity
2493 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FSE
Engine model
2ar-fe
Engine placement
Front, longitudinal
Engine power
321 hp
Engine type
Hybrid
Fuel tank capacity
71 l
Injection type
distributed injection (multipoint)
Max power (kW)
236 kW
Max power at RPM
6000 RPM
Maximum torque
221 N*m
Stroke cycle
98 mm
Turnover of maximum torque
4800 RPM
fuel
Mixed driving fuel consumption per 100 km
4.8 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1545 mm
Clearance
155 mm
Curb weight
1710 kg
Front track width
1545 mm
Full weight
1915 kg
Height
1460 mm
Length
4895 mm
Number of doors
4
Wheelbase
2850 mm
Width
1800 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
225/50 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Sedan
Car class
E
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT (173 hp)
Привід Front wheel drive
КПП Automatic
Camry 7 (XV50)
2011–2014
173 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
173 hp
Engine type
Gasoline
Fuel tank capacity
64 l
Injection type
distributed injection (multipoint)
Max power (kW)
127 kW
Max power at RPM
6000 RPM
Maximum torque
224 N*m
Min trunk capacity
436 l
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
9.0 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
9.4 l
Highway driving fuel consumption per 100 km
6.7 l
Mixed driving fuel consumption per 100 km
8.4 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1575 mm
Clearance
155 mm
Curb weight
1448 kg
Front track width
1585 mm
Height
1471 mm
Length
4806 mm
Number of doors
4
Wheelbase
2776 mm
Width
1821 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
205/65 R16
other
Body type
Sedan
Car class
E
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT (178 hp)
Привід Front wheel drive
КПП Automatic
Camry 7 (XV50)
2011–2014
178 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
178 hp
Engine type
Gasoline
Fuel tank capacity
64 l
Injection type
distributed injection (multipoint)
Max power (kW)
131 kW
Max power at RPM
6000 RPM
Maximum torque
231 N*m
Min trunk capacity
436 l
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
9.0 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
9.4 l
Highway driving fuel consumption per 100 km
6.7 l
Mixed driving fuel consumption per 100 km
8.4 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1575 mm
Clearance
155 mm
Curb weight
1448 kg
Front track width
1585 mm
Height
1471 mm
Length
4806 mm
Number of doors
4
Wheelbase
2776 mm
Width
1821 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
205/65 R16
other
Body type
Sedan
Car class
E
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT (181 hp)
Привід Front wheel drive
КПП Automatic
Camry 7 (XV50)
2011–2014
181 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90.0 mm
Engine code
2AR-FE
Engine placement
Front, transverse
Engine power
181 hp
Engine type
Gasoline
Fuel tank capacity
70 l
Injection type
distributed injection (multipoint)
Max power (kW)
133 kW
Max power at RPM
6000 RPM
Max trunk capacity
506 l
Maximum torque
231 N*m
Min trunk capacity
506 l
Stroke cycle
98.0 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
9.0 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
11.0 l
CO2 emissions
183 g/km
Cruising range
from 640 to 1 190 km
Emission standards
Euro 4
Highway driving fuel consumption per 100 km
5.9 l
Mixed driving fuel consumption per 100 km
7.8 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1565 mm
Clearance
160 mm
Curb weight
1510 kg
Front track width
1575 mm
Full weight
2100 kg
Ground clearance
160 mm
Height
1480 mm
Length
4825 mm
Number of doors
4
Wheelbase
2775 mm
Width
1825 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left
Wheel size
205/65 R16
other
Body type
Sedan
Car class
E
Front track
1575 mm
Front/rear axle load
965/1135 kg
Number of seater
5
Payload
590 kg
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1565 mm
Turning circle
11 m
2.5 AT (181 hp)
Привід Front wheel drive
КПП Automatic
Zelas 1
2010–2013
181 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2AR-FE
Engine placement
Front, transverse
Engine power
181 hp
Engine type
Gasoline
Fuel tank capacity
55 l
Injection type
direct injection (direct)
Max power (kW)
133 kW
Max power at RPM
6000 RPM
Maximum torque
233 N*m
Min trunk capacity
416 l
Stroke cycle
98 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
7.4 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
10.0 l
Highway driving fuel consumption per 100 km
7.6 l
Mixed driving fuel consumption per 100 km
9.0 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1560 mm
Clearance
160 mm
Curb weight
1400 kg
Front track width
1539 mm
Height
1415 mm
Length
4420 mm
Number of doors
2
Wheelbase
2700 mm
Width
1796 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left
Wheel size
215/50 R17
other
Body type
Coupe
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT 4WD (182 hp)
Привід Front wheel drive
КПП Automatic
RAV4 CA30 [рест.]
2010–2016
182 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, transverse
Engine power
182 hp
Engine type
Gasoline
Fuel tank capacity
60 l
Injection type
distributed injection (multipoint)
Max power (kW)
134 kW
Max power at RPM
6000 RPM
Maximum torque
233 N*m
Min trunk capacity
540 l
Stroke cycle
98 mm
performance
Acceleration (0-100 km/h)
9.4 s
Max speed
180 km/h
fuel
Emission standards
Euro 4
Highway driving fuel consumption per 100 km
8.4 l
Mixed driving fuel consumption per 100 km
10.7 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1560 mm
Clearance
190 mm
Front track width
1560 mm
Height
1720 mm
Length
4625 mm
Number of doors
5
Wheelbase
2660 mm
Width
1855 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
235/55 R18
other
Body type
Crossover
Car class
C
Disc size
6.5x17 ET39, 7.5x18 ET45, 7x17 ET39
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT (169 hp)
Привід Front wheel drive
КПП Automatic
Camry 6 (XV40) [рест.]
2009–2011
169 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, transverse
Engine type
Gasoline
Fuel tank capacity
70 l
Injection type
distributed injection (multipoint)
Maximum torque
233 N*m
Min trunk capacity
535 l
Stroke cycle
98 mm
Turnover of maximum torque
4100 RPM
performance
Acceleration (0-100 km/h)
6.8 s
Max speed
230 km/h
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1575 mm
Clearance
140 mm
Curb weight
1500 kg
Front track width
1580 mm
Full weight
1910 kg
Height
1480 mm
Length
4815 mm
Number of doors
4
Wheelbase
2775 mm
Width
1820 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/60 R16
other
Body type
Sedan
Car class
E
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT Overdrive (179 hp)
Привід Front wheel drive
КПП Automatic
Camry 6 (XV40) [рест.]
2006–2009
179 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, transverse
Engine power
179 hp
Engine type
Gasoline
Fuel tank capacity
70 l
Injection type
distributed injection (multipoint)
Max power at RPM
to 6 000 RPM
Max trunk capacity
411 l
Maximum torque
233 N*m
Min trunk capacity
535 l
Stroke cycle
98 mm
Turnover of maximum torque
to 4 100 RPM
performance
Acceleration (0-100 km/h)
9.0 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
11.0 l
Cruising range
from 660 to 960 km
Emission standards
EURO V
Highway driving fuel consumption per 100 km
5.9 l
Mixed driving fuel consumption per 100 km
7.8 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1575 mm
Clearance
160 mm
Curb weight
1510 kg
Front track width
1580 mm
Full weight
2100 kg
Ground clearance
135 mm
Height
1480 mm
Length
4815 mm
Number of doors
4
Wheelbase
2775 mm
Width
1820 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/60 R16
other
Body type
Sedan
Car class
E
Front track
1575 mm
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Rear track
1565 mm
Turning circle
11 m
2.5 MT (169 hp)
Привід Front wheel drive
КПП Manual
Camry 6 (XV40) [рест.]
2009–2011
169 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, transverse
Engine type
Gasoline
Fuel tank capacity
70 l
Injection type
distributed injection (multipoint)
Maximum torque
233 N*m
Min trunk capacity
535 l
Stroke cycle
98 mm
performance
Acceleration (0-100 km/h)
9.0 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
10.6 l
Highway driving fuel consumption per 100 km
7.1 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1575 mm
Clearance
160 mm
Curb weight
1490 kg
Front track width
1580 mm
Full weight
2100 kg
Height
1480 mm
Length
4815 mm
Number of doors
4
Wheelbase
2775 mm
Width
1820 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/60 R16
other
Body type
Sedan
Car class
E
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT (179 hp)
Привід Front wheel drive
КПП Automatic
Camry 6 (XV40)
2006–2009
179 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, transverse
Engine type
Gasoline
Fuel tank capacity
70 l
Injection type
distributed injection (multipoint)
Maximum torque
233 N*m
Min trunk capacity
535 l
Stroke cycle
98 mm
performance
Acceleration (0-100 km/h)
9.0 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
11.0 l
Highway driving fuel consumption per 100 km
5.9 l
Mixed driving fuel consumption per 100 km
7.8 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
6
dimensions
Back track width
1565 mm
Clearance
160 mm
Curb weight
1510 kg
Front track width
1575 mm
Full weight
2100 kg
Height
1480 mm
Length
4815 mm
Number of doors
4
Wheelbase
2775 mm
Width
1820 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/60 R16
other
Body type
Sedan
Car class
E
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 MT (179 hp)
Привід Front wheel drive
КПП Manual
Camry 6 (XV40)
2006–2009
179 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, transverse
Engine type
Gasoline
Fuel tank capacity
70 l
Injection type
distributed injection (multipoint)
Maximum torque
233 N*m
Min trunk capacity
535 l
Stroke cycle
98 mm
performance
Acceleration (0-100 km/h)
9.0 s
Max speed
210 km/h
fuel
City driving fuel consumption per 100 km
10.6 l
Highway driving fuel consumption per 100 km
7.1 l
Mixed driving fuel consumption per 100 km
9.8 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1565 mm
Clearance
160 mm
Curb weight
1490 kg
Front track width
1575 mm
Full weight
2100 kg
Height
1480 mm
Length
4815 mm
Number of doors
4
Wheelbase
2775 mm
Width
1820 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/60 R16
other
Body type
Sedan
Car class
E
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT (179 hp)
Привід Front wheel drive
КПП Automatic
RAV4 3 (XA30)
2005–2010
179 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, longitudinal
Engine type
Gasoline
Fuel tank capacity
60 l
Injection type
distributed injection (multipoint)
Max trunk capacity
1469 l
Maximum torque
233 N*m
Min trunk capacity
586 l
Stroke cycle
98 mm
performance
Acceleration (0-100 km/h)
9.9 s
fuel
City driving fuel consumption per 100 km
10.7 l
Emission standards
Euro 4
Highway driving fuel consumption per 100 km
8.4 l
transmission
Drive wheels
Front wheel drive
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1560 mm
Clearance
190 mm
Front track width
1560 mm
Height
1685 mm
Length
4395 mm
Number of doors
5
Wheelbase
2560 mm
Width
1815 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/70 R16
other
Body type
Crossover
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 AT (182 hp)
Привід All wheel drive (AWD)
КПП Automatic
RAV4 3 (XA30)
2005–2010
182 hp
engine
Capacity
2494 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FE
Engine model
2ar-fe
Engine placement
Front, transverse
Engine type
Gasoline
Fuel tank capacity
60 l
Injection type
distributed injection (multipoint)
Max trunk capacity
1469 l
Maximum torque
233 N*m
Min trunk capacity
586 l
Stroke cycle
98 mm
fuel
Emission standards
Euro 4
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1560 mm
Clearance
190 mm
Front track width
1560 mm
Height
1755 mm
Length
4620 mm
Number of doors
5
Wheelbase
2660 mm
Width
1855 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/70 R16
other
Body type
Crossover
Car class
C
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
2.5 CVT (321 hp)
Привід Rear wheel drive
КПП Continuously variable transmission (CVT)
Crown 2 (S40)
1965–1967
321 hp
engine
Capacity
2493 cm3
Compression ratio
10.4
Cylinder bore
90 mm
Engine code
2AR-FSE
Engine model
2ar-fe
Engine placement
Front, longitudinal
Engine power
321 hp
Engine type
Hybrid
Fuel tank capacity
65 l
Injection type
distributed injection (multipoint)
Max power (kW)
236 kW
Max power at RPM
6000 RPM
Maximum torque
221 N*m
Stroke cycle
98 mm
Turnover of maximum torque
4800 RPM
fuel
CO2 emissions
100 g/km
Mixed driving fuel consumption per 100 km
4.3 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Continuously variable transmission (CVT)
dimensions
Back track width
1545 mm
Clearance
135 mm
Curb weight
1660 kg
Front track width
1545 mm
Full weight
1935 kg
Height
1460 mm
Length
4895 mm
Number of doors
4
Wheelbase
2850 mm
Width
1800 mm
suspension
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
215/55 R17
other
Battery type
Nickel metal hydride (NiMH)
Body type
Sedan
Car class
E
Number of seater
5
Pitch Circle Diameter
DIA60.1 5x114.3 mm
Автомобілі з двигуном 2AR-FE
Цей двигун встановлювався на 8 моделей
| Фото | Бренд | Модель | Генерація | Роки випуску |
|---|---|---|---|---|
|
Немає фото
|
Lexus | ES | ES VI (XV60) | 2013 - 2018 |
|
Немає фото
|
Lexus | GS | GS IV (L10) | 2011 - 2020 |
|
Немає фото
|
Lexus | IS | IS II (XE20) | 2006 - 2013 |
|
Немає фото
|
Lexus | IS | IS III (XE30) | 2014 - present |
|
Немає фото
|
Scion | tC | tC II | 2011 - 2016 |
|
Toyota | Camry | Camry VII (XV40) | 2006 - 2011 |
|
Toyota | Camry | Camry VIII (XV50) | 2011 - 2017 |
|
Toyota | Highlander | Highlander III (U50) | 2013 - 2020 |
|
Немає фото
|
Toyota | RAV4 | RAV4 IV (HA40) | 2013 - 2018 |
|
Toyota | Venza | Venza | 2008 - 2016 |
Всі модифікації (30)
| Автомобіль | Генерація | Модифікація | Потужність | Коробка | Привід |
|---|---|---|---|---|---|
| Lexus ES | ES VI (XV60) | 2.5 4-циліндровий 204 л.с. 8-Автомат 2WD | 204 л.с. | 8-Автомат | 2WD |
| Lexus ES | ES VI (XV60) | 2.5 4-циліндровий 204 л.с. 8-Автомат 4x4 | 204 л.с. | 8-Автомат | 4x4 |
| Lexus GS | GS IV (L10) | 2.5 V6 206 л.с. 6-МКП 2WD | 206 л.с. | 6-МКП | 2WD |
| Lexus GS | GS IV (L10) | 2.5 V6 206 л.с. 8-Автомат 2WD | 206 л.с. | 8-Автомат | 2WD |
| Lexus IS | IS II (XE20) | 2.0 150 л.с. 6-МКП 2WD | 150 л.с. | 6-МКП | 2WD |
| Lexus IS | IS II (XE20) | 2.0 150 л.с. 7-Автомат 2WD | 150 л.с. | 7-Автомат | 2WD |
| Lexus IS | IS III (XE30) | 2.0 4-cylinder 150 л.с. 6-МКП 2WD | 150 л.с. | 6-МКП | 2WD |
| Lexus IS | IS III (XE30) | 2.0 4-cylinder 150 л.с. 8-Автомат 2WD | 150 л.с. | 8-Автомат | 2WD |
| Lexus IS | IS III (XE30) | 2.5 4-cylinder 204 л.с. 6-МКП 2WD | 204 л.с. | 6-МКП | 2WD |
| Lexus IS | IS III (XE30) | 2.5 4-cylinder 204 л.с. 8-Автомат 2WD | 204 л.с. | 8-Автомат | 2WD |
| Lexus IS | IS III (XE30) | 2.5 4-cylinder 204 л.с. 6-МКП 4x4 | 204 л.с. | 6-МКП | 4x4 |
| Lexus IS | IS III (XE30) | 2.5 4-cylinder 204 л.с. 8-Автомат 4x4 | 204 л.с. | 8-Автомат | 4x4 |
| Scion tC | tC II | 2.5L I4 179 л.с. 6-МКП 2WD | 179 л.с. | 6-МКП | 2WD |
| Scion tC | tC II | 2.5L I4 179 л.с. 6-Автомат 2WD | 179 л.с. | 6-Автомат | 2WD |
| Scion tC | tC II | 2.5L I4 179 л.с. 6-МКП 4x4 | 179 л.с. | 6-МКП | 4x4 |
| Scion tC | tC II | 2.5L I4 179 л.с. 6-Автомат 4x4 | 179 л.с. | 6-Автомат | 4x4 |
| Toyota Camry | Camry VII (XV40) | 2.5 2AR-FE 169 л.с. 6-МКП 2WD | 169 л.с. | 6-МКП | 2WD |
| Toyota Camry | Camry VII (XV40) | 2.5 2AR-FE 169 л.с. 6-Автомат 2WD | 169 л.с. | 6-Автомат | 2WD |
| Toyota Camry | Camry VIII (XV50) | 2.0 150 л.с. 6-МКП 2WD | 150 л.с. | 6-МКП | 2WD |
| Toyota Camry | Camry VIII (XV50) | 2.0 150 л.с. 7-Автомат 2WD | 150 л.с. | 7-Автомат | 2WD |
| Toyota Camry | Camry VIII (XV50) | 2.5 181 л.с. 6-МКП 2WD | 181 л.с. | 6-МКП | 2WD |
| Toyota Camry | Camry VIII (XV50) | 2.5 181 л.с. 7-Автомат 2WD | 181 л.с. | 7-Автомат | 2WD |
| Toyota Highlander | Highlander III (U50) | 2.7L 4-циліндровий 185 л.с. 6-МКП 2WD | 185 л.с. | 6-МКП | 2WD |
| Toyota Highlander | Highlander III (U50) | 2.7L 4-циліндровий 185 л.с. 6-Автомат 2WD | 185 л.с. | 6-Автомат | 2WD |
| Toyota RAV4 | RAV4 IV (HA40) | 2.5 152 л.с. 6-Автомат 2WD | 152 л.с. | 6-Автомат | 2WD |
| Toyota RAV4 | RAV4 IV (HA40) | 2.5 152 л.с. 6-МКП 2WD | 152 л.с. | 6-МКП | 2WD |
| Toyota RAV4 | RAV4 IV (HA40) | 2.5 152 л.с. 6-Автомат 4x4 | 152 л.с. | 6-Автомат | 4x4 |
| Toyota RAV4 | RAV4 IV (HA40) | 2.5 152 л.с. 6-МКП 4x4 | 152 л.с. | 6-МКП | 4x4 |
| Toyota Venza | Venza | 2.7L I4 182 л.с. 6-МКП 2WD | 182 л.с. | 6-МКП | 2WD |
| Toyota Venza | Venza | 2.7L I4 182 л.с. 6-Автомат 2WD | 182 л.с. | 6-Автомат | 2WD |
Цікаві факти
- The 2AR-FE engine is known for its reliability and fuel efficiency.
- It features Dual VVT-i for improved performance and efficiency.
Застосування
| Автомобіль | Генерація | Роки | Потужність | Ринки |
|---|---|---|---|---|
| Toyota Camry | XV50 | 2011-2019 | 147hp/158hp | Global |
| Toyota RAV4 | XA40 | 2013-2018 | 147hp/158hp | Global |
Сумісні трансмісії: 6-speed Automatic, 6-speed Manual
Типи приводу: FWD, AWD
Fuel Economy
| Fuel Type | Petrol 95 |
| Octane Rating | Мінімум: 91 | Рекомендовано: 95 |
| Consumption (City) | 9 л/100км |
| Consumption (Highway) | 6 л/100км |
| Consumption (Combined) | 7.5 л/100км |
| Real Consumption | 8 л/100км |
| Fuel Tank Capacity | 55 л |
| Range | 733 км |
| Cost per 100 km | 10-12 USD |
Emissions Standards
| Emission Standard | Euro 5 |
| CO₂ Emissions | 155 г/км |
| Particulate Filter (DPF) | Absent |
| AdBlue | Not Required |
Порівняння з конкурентами
| Двигун | Бренд | Об'єм | Потужність | Крутний момент |
|---|---|---|---|---|
| K20Z3 | Honda | 1,998 см³ | 200 л.с. | 190 Н*м |
| MZR 2.0 | Mazda | 1,999 см³ | 155 л.с. | 200 Н*м |
Переваги
- Good balance of power and fuel efficiency
- Reliable and durable design
Недоліки
- Limited tuning potential compared to turbocharged engines
- Some models may experience oil consumption issues
Корисні ресурси
| Технічна документація | https://www.toyota-global.com/technical_specifications |
| Форуми та обговорення |
