2UZ-FE Toyota 2UZ-FE
4.5-літровий V8 двигун Toyota, відомий своєю надійністю та довговічністю, використовується в позашляховиках та пікапах.
74
Brand engines
16
Modifications
Technical Specifications
| Engine Displacement | 4.5 L (4,663 cc) |
| Configuration | V8 |
| Number of Cylinders | 8 |
| Valves per Cylinder | 4 |
| Power | 230 - 300 л.с. |
| Torque | 420 - 460 Н*м |
| Cylinder Bore | 94.00 mm |
| Piston Stroke | 84.00 mm |
| Compression Ratio | 9.6:1 |
| Firing Order | 1-8-4-3-6-5-7-2 |
| Fuel System | Multi-point fuel injection |
| Aspiration | Naturally Aspirated |
| Intercooler | No |
| Maximum RPM | 5,400 rpm |
| Max Torque RPM | 3,200 rpm |
| Valve Train | DOHC |
| Timing Drive | Chain |
| Timing Chain Replacement | 200000 or as needed |
| Block Material | Aluminum |
| Head Material | Aluminum |
| Engine Weight | 220 kg |
| Dimensions (L×W×H) | 700 × 600 × 600 mm |
| Lubrication System | Wet sump |
| Cooling System | Liquid cooling |
Additional Information
| Engine Family | Toyota UZ engine family |
| Manufacturing Plant | Toyota City, Japan |
| Predecessor | 1UZ-FE |
Maintenance
| Engine Oil Capacity | 6 L (with filter: 6.5 L) |
| Recommended Viscosity | 5W-30, 10W-30 |
| Oil Standard | API SL/SM |
| Recommended Brands | Toyota Genuine Oil, Mobil 1, Castrol Edge |
| Oil Change Interval | 8 000 km or 6 mo |
| Oil Filter | 90915-YZZD1 |
| Air Filter |
17801-50030
Replace every 48 000 km |
| Spark Plugs |
Type: Iridium Part number: 90080-91113Gap: 1.1 mm Quantity: 8 pcs Replace every 96 000 km |
| Coolant Capacity | 10 L |
| Coolant Type | Toyota Super Long Life Coolant (Toyota Coolant) |
| Coolant Change Interval | 160 000 km |
| Thermostat Opening Temperature | 82°C |
| Operating Temperature | 90°C |
| Max Operating Temperature | 110°C |
| Critical Temperature | 120°C |
| Annual Maintenance Cost | 600-900 USD |
Reliability
Expected lifespan: 300 000 km
Common problems
| Problem | Severity | Mileage | Repair cost |
|---|---|---|---|
| Oil leaks from valve covers | Medium | 150000-200000 km | $300-500 |
| Timing chain tensioner failure | High | 200000-250000 km | $800-1200 |
Known defects
- Some early models had issues with the head gasket
- Oil consumption in high mileage engines
Warranty extensions
- Toyota offers extended warranties for certain components up to 100000 miles
Tuning potential
Tuning potential: Medium | Max. safe power: 450 hp
| Stage | Power | Torque | Method | Cost |
|---|---|---|---|---|
| Stage 1 | 320 hp | 480 Nm |
ECU remap only Reliability impact: Minimal |
$600 |
| Stage 2 | 360 hp | 520 Nm |
ECU, Exhaust System Required: Cold air intake, High-performance exhaust Reliability impact: Low |
$1500 |
| Stage 3 | 400 hp | 580 Nm |
- Required: Upgraded turbo, Forged internals Reliability impact: Medium |
$3000 |
Popular modifications
- ECU tune
- Cold air intake
- High-performance exhaust system
Tuning limitations
- Stock internals limit power potential
- Cooling system upgrades necessary for high power levels
Детальні технічні характеристики
42
модифікацій
235–288
к.с.
Спільні характеристики
| Boost type | none |
| Capacity | 4664 cm3 |
| Car class | J |
| Country | Japan |
| Cylinder layout | V-type |
| Engine code | 2UZ-FE |
| Engine placement | Front, longitudinal |
| Engine type | Gasoline |
| Front suspension | Independent, spring |
| Fuel | 95 |
| Injection type | distributed injection (multipoint) |
| Number of cylinders | 8 |
| Timing belt | DOHC |
| Valves per cylinder | 4 |
Модифікації двигуна
4.7 AT (276 hp)
Привід All wheel drive (AWD)
КПП Automatic
Tundra 2
2007–2013
276 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
276 hp
Fuel tank capacity
100 l
Max power (kW)
203 kW
Max power at RPM
4800 RPM
Maximum torque
424 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
7.5 s
Max speed
170 km/h
fuel
City driving fuel consumption per 100 km
16.1 l
Highway driving fuel consumption per 100 km
13.5 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1725 mm
Clearance
260 mm
Curb weight
2438 kg
Front track width
1725 mm
Height
1930 mm
Length
5809 mm
Number of doors
4
Wheelbase
3701 mm
Width
2029 mm
suspension
Back suspension
Dependent, spring
Front brakes
Disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
255/70 R18
other
Body type
Pickup
Number of seater
5
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT (276 hp)
Привід All wheel drive (AWD)
КПП Automatic
Sequoia 2
2007–2009
276 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
276 hp
Fuel tank capacity
100 l
Max power (kW)
203 kW
Max power at RPM
4800 RPM
Max trunk capacity
3401 l
Maximum torque
424 N*m
Min trunk capacity
535 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
11.5 s
Max speed
100 km/h
fuel
City driving fuel consumption per 100 km
18.1 l
Cruising range
from 600 to 1 000 km
Highway driving fuel consumption per 100 km
14.7 l
Mixed driving fuel consumption per 100 km
12.5 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1725 mm
Clearance
254 mm
Curb weight
2685 kg
Front track width
1725 mm
Full weight
3175 kg
Ground clearance
251 mm
Height
1895 mm
Length
5210 mm
Number of doors
5
Wheelbase
3099 mm
Width
2027 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left
Trailer load (with brakes)
7693 kg
Wheel size
275/65 R18
other
Body type
Crossover
Front track
1725 mm
Number of seater
8
Payload
599 kg
Pitch Circle Diameter
DIA110 5x150 mm
Rear track
1755 mm
Turning circle
11.61 m
4.7 AT (276 hp)
Привід Rear wheel drive
КПП Automatic
Tundra 2
2007–2013
276 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
276 hp
Fuel tank capacity
100 l
Max power (kW)
203 kW
Max power at RPM
4800 RPM
Maximum torque
424 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
fuel
City driving fuel consumption per 100 km
15.7 l
Highway driving fuel consumption per 100 km
13.1 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1648 mm
Clearance
264 mm
Curb weight
2438 kg
Front track width
1681 mm
Height
1796 mm
Length
5545 mm
Number of doors
2
Wheelbase
3259 mm
Width
2029 mm
suspension
Back suspension
Dependent, spring
Front brakes
Disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
255/70 R18
other
Body type
Pickup
Number of seater
2
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT 4WD (288 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 200 Series
2007–2012
288 hp
engine
Compression ratio
10
Cylinder bore
94.0 mm
Engine model
2uz-fe
Engine power
288 hp
Fuel tank capacity
93 l
Max power (kW)
212 kW
Max power at RPM
5400 RPM
Max trunk capacity
1267 l
Maximum torque
445 N*m
Min trunk capacity
701 l
Stroke cycle
84.0 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
9.5 s
Max speed
200 km/h
fuel
City driving fuel consumption per 100 km
19.0 l
Highway driving fuel consumption per 100 km
11.7 l
Mixed driving fuel consumption per 100 km
14.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1635 mm
Clearance
225 mm
Curb weight
2585 kg
Front track width
1640 mm
Full weight
3300 kg
Height
1950 mm
Length
4950 mm
Number of doors
5
Wheelbase
2850 mm
Width
1970 mm
suspension
Back suspension
Dependent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
275/65 R17, 285/60 R18
other
Body type
Crossover
Disc size
8.5x20 ET60, 8x17 ET60, 8x18 ET60
Number of seater
7
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT AWD (288 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 200 Series
2007–2012
288 hp
engine
Compression ratio
10
Cylinder bore
94.0 mm
Engine model
2uz-fe
Engine power
288 hp
Fuel tank capacity
93 l
Max power (kW)
212 kW
Max power at RPM
5400 RPM
Max trunk capacity
1267 l
Maximum torque
445 N*m
Min trunk capacity
701 l
Stroke cycle
84.0 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
9.5 s
Max speed
200 km/h
fuel
City driving fuel consumption per 100 km
19.0 l
Highway driving fuel consumption per 100 km
11.7 l
Mixed driving fuel consumption per 100 km
14.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1635 mm
Clearance
225 mm
Curb weight
2585 kg
Front track width
1640 mm
Full weight
3300 kg
Height
1950 mm
Length
4950 mm
Number of doors
5
Wheelbase
2850 mm
Width
1970 mm
suspension
Back suspension
Dependent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
275/65 R17, 285/60 R18
other
Body type
Crossover
Number of seater
7
Pitch Circle Diameter
DIA110 5x150 mm
4.7 MT (276 hp)
Привід Rear wheel drive
КПП Manual
Tundra 2
2007–2013
276 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
276 hp
Fuel tank capacity
100 l
Max power (kW)
203 kW
Max power at RPM
4800 RPM
Maximum torque
424 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
6.5 s
Max speed
170 km/h
transmission
Drive wheels
Rear wheel drive
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1725 mm
Clearance
260 mm
Curb weight
2438 kg
Front track width
1725 mm
Height
1930 mm
Length
5809 mm
Number of doors
4
Wheelbase
3701 mm
Width
2029 mm
suspension
Back suspension
Dependent, spring
Front brakes
Disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
255/70 R18
other
Body type
Pickup
Number of seater
5
Pitch Circle Diameter
DIA110 5x150 mm
4.7 MT (276 hp)
Привід Rear wheel drive
КПП Manual
Tundra 2
2007–2013
276 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
276 hp
Fuel tank capacity
100 l
Max power (kW)
203 kW
Max power at RPM
4800 RPM
Maximum torque
424 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
6.5 s
transmission
Drive wheels
Rear wheel drive
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1648 mm
Clearance
260 mm
Curb weight
2438 kg
Front track width
1681 mm
Height
1796 mm
Length
5545 mm
Number of doors
2
Wheelbase
3259 mm
Width
2029 mm
suspension
Back suspension
Dependent, spring
Front brakes
Disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
255/70 R18
other
Body type
Pickup
Number of seater
2
Pitch Circle Diameter
DIA110 5x150 mm
4.7 (260 hp)
Привід All wheel drive (AWD)
КПП Automatic
4Runner 4 [рест.]
2005–2009
260 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
260 hp
Fuel tank capacity
87 l
Max power (kW)
191 kW
Max power at RPM
4800 RPM
Max trunk capacity
2127 l
Maximum torque
415 N*m
Min trunk capacity
1036 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
7.5 s
fuel
City driving fuel consumption per 100 km
15.7 l
Highway driving fuel consumption per 100 km
12.4 l
Mixed driving fuel consumption per 100 km
12.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1575 mm
Clearance
231 mm
Curb weight
2070 kg
Front track width
1575 mm
Full weight
2724 kg
Height
1760 mm
Length
4806 mm
Number of doors
5
Wheelbase
2788 mm
Width
1911 mm
suspension
Back suspension
Dependent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
225/75 R15
other
Body type
Crossover
Disc size
10x24 ET5, 7.5x17 ET6, 7.5x18 ET6, 7x15 ET6, 7x16 ET6, 9.5x22 ET4, 9x20 ET10
Number of seater
5, 8
Pitch Circle Diameter
DIA106 6x139.7 mm
4.7 AT 4WD (235 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 100 Series [2th restyling]
2005–2007
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
2212 l
Maximum torque
434 N*m
Min trunk capacity
1318 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
13.6 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
21.5 l
Highway driving fuel consumption per 100 km
13.4 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1600 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1605 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1940 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
275/70 R16
other
Body type
Crossover
Disc size
8x16 ET60, 8x17 ET60, 8x18 ET60
Number of seater
5, 8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT 4WD (235 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 100 Series [2th restyling]
2005–2007
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
2212 l
Maximum torque
434 N*m
Min trunk capacity
1318 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
21.5 l
Highway driving fuel consumption per 100 km
13.4 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1615 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1620 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1620 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Right
Wheel size
275/70 R16
other
Body type
Crossover
Disc size
8x16 ET60, 8x17 ET60, 8x18 ET60
Number of seater
8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT AWD (235 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 100 Series [2th restyling]
2005–2007
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
2212 l
Maximum torque
434 N*m
Min trunk capacity
1318 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
21.5 l
Highway driving fuel consumption per 100 km
13.4 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1615 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1620 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1620 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Right
Wheel size
275/70 R16
other
Body type
Crossover
Number of seater
8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 MT 4WD (235 hp)
Привід All wheel drive (AWD)
КПП Manual
Land Cruiser 100 Series [2th restyling]
2005–2007
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
2212 l
Maximum torque
434 N*m
Min trunk capacity
1318 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.7 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
22.4 l
Highway driving fuel consumption per 100 km
13.3 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
5
dimensions
Back track width
1600 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1605 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1940 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
275/70 R16
other
Body type
Crossover
Disc size
8x16 ET60, 8x17 ET60, 8x18 ET60
Number of seater
5, 8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT (271 hp)
Привід All wheel drive (AWD)
КПП Automatic
Sequoia 1 [рест.]
2004–2007
271 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
271 hp
Fuel tank capacity
100 l
Max power (kW)
199 kW
Max power at RPM
4800 RPM
Max trunk capacity
3627 l
Maximum torque
427 N*m
Min trunk capacity
787 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
12.8 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
23.0 l
Highway driving fuel consumption per 100 km
13.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1709 mm
Clearance
250 mm
Curb weight
2300 kg
Front track width
1674 mm
Full weight
2950 kg
Height
1854 mm
Length
5179 mm
Number of doors
5
Wheelbase
3000 mm
Width
2004 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left
Wheel size
245/70 R16
other
Body type
Crossover
Number of seater
5, 8
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 AT (282 hp)
Привід All wheel drive (AWD)
КПП Automatic
Sequoia 1 [рест.]
2004–2005
282 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
282 hp
Fuel tank capacity
100 l
Max power (kW)
207 kW
Max power at RPM
4800 RPM
Max trunk capacity
3627 l
Maximum torque
440 N*m
Min trunk capacity
787 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
12.8 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
23.0 l
Cruising range
from 640 to 770 km
Highway driving fuel consumption per 100 km
13.0 l
Mixed driving fuel consumption per 100 km
15.7 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1709 mm
Clearance
250 mm
Curb weight
2300 kg
Front track width
1674 mm
Full weight
2950 kg
Ground clearance
254 mm
Height
1854 mm
Length
5179 mm
Number of doors
5
Wheelbase
3000 mm
Width
2004 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left
Trailer load (with brakes)
5443 kg
Wheel size
245/70 R16
other
Body type
Crossover
Front track
1674 mm
Number of seater
5, 8
Payload
782 kg
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1709 mm
Turning circle
14 m
4.7 AT (235 hp)
Привід Rear wheel drive
КПП Automatic
4Runner 4
2002–2005
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
87 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
2127 l
Maximum torque
434 N*m
Min trunk capacity
1195 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
8.0 s
Max speed
188 km/h
fuel
City driving fuel consumption per 100 km
14.7 l
Highway driving fuel consumption per 100 km
11.8 l
Mixed driving fuel consumption per 100 km
12.4 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1575 mm
Clearance
231 mm
Curb weight
1955 kg
Front track width
1575 mm
Full weight
2382 kg
Height
1755 mm
Length
4800 mm
Number of doors
5
Wheelbase
2790 mm
Width
1875 mm
suspension
Back suspension
Dependent, spring
Front brakes
Disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
265/70 R16
other
Body type
Crossover
Number of seater
5, 8
Pitch Circle Diameter
DIA106 6x139.7 mm
4.7 AT (245 hp)
Привід All wheel drive (AWD)
КПП Automatic
Tundra 1 [рест.]
2002–2006
245 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
245 hp
Fuel tank capacity
100 l
Max power (kW)
180 kW
Max power at RPM
4800 RPM
Maximum torque
434 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
7.8 s
Max speed
170 km/h
fuel
City driving fuel consumption per 100 km
16.8 l
Highway driving fuel consumption per 100 km
13.8 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1648 mm
Clearance
274 mm
Front track width
1681 mm
Height
1796 mm
Length
5545 mm
Number of doors
2
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
ventilated disc
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
4
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 AT (245 hp)
Привід All wheel drive (AWD)
КПП Automatic
Tundra 1 [рест.]
2002–2004
245 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
245 hp
Fuel tank capacity
100 l
Max power (kW)
180 kW
Max power at RPM
4800 RPM
Maximum torque
434 N*m
Min trunk capacity
2625 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
7.8 s
Max speed
170 km/h
fuel
City driving fuel consumption per 100 km
16.8 l
Highway driving fuel consumption per 100 km
13.8 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1648 mm
Clearance
274 mm
Front track width
1674 mm
Height
1816 mm
Length
5545 mm
Number of doors
4
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
ventilated disc
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 AT (271 hp)
Привід All wheel drive (AWD)
КПП Automatic
Tundra 1 [рест.]
2002–2006
271 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
271 hp
Fuel tank capacity
100 l
Max power (kW)
199 kW
Max power at RPM
4800 RPM
Maximum torque
427 N*m
Min trunk capacity
2625 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
fuel
City driving fuel consumption per 100 km
15.6 l
Highway driving fuel consumption per 100 km
13.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1648 mm
Clearance
274 mm
Front track width
1674 mm
Height
1816 mm
Length
5545 mm
Number of doors
4
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
ventilated disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 AT (271 hp)
Привід All wheel drive (AWD)
КПП Automatic
Tundra 1 [рест.]
2002–2006
271 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
271 hp
Fuel tank capacity
100 l
Max power (kW)
199 kW
Max power at RPM
4800 RPM
Maximum torque
427 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
fuel
City driving fuel consumption per 100 km
15.6 l
Highway driving fuel consumption per 100 km
13.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1648 mm
Clearance
274 mm
Front track width
1681 mm
Height
1796 mm
Length
5545 mm
Number of doors
2
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
ventilated disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
4
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 AT (271 hp) 4WD
Привід All wheel drive (AWD)
КПП Automatic
4Runner 4
2003–2005
271 hp
engine
Compression ratio
10
Cylinder bore
94.0 mm
Engine power
271 hp
Fuel tank capacity
87 l
Max power (kW)
199 kW
Max power at RPM
4800 RPM
Max trunk capacity
2127 l
Maximum torque
427 N*m
Min trunk capacity
1195 l
Stroke cycle
84.0 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
8.0 s
Max speed
188 km/h
fuel
City driving fuel consumption per 100 km
15.7 l
Highway driving fuel consumption per 100 km
12.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1575 mm
Clearance
240 mm
Curb weight
1955 kg
Front track width
1575 mm
Full weight
2382 kg
Height
1755 mm
Length
4800 mm
Number of doors
5
Wheelbase
2790 mm
Width
1875 mm
suspension
Back suspension
Dependent, spring
Front brakes
Disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
265/70 R16
other
Body type
Crossover
Number of seater
5, 8
Pitch Circle Diameter
DIA106 6x139.7 mm
4.7 AT 4WD (235 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 100 Series [рест.]
2002–2005
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
2212 l
Maximum torque
434 N*m
Min trunk capacity
1318 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
21.5 l
Highway driving fuel consumption per 100 km
13.4 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1615 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1620 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1940 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Right
Wheel size
275/70 R16
other
Body type
Crossover
Disc size
8x16 ET60, 8x17 ET60, 8x18 ET60
Number of seater
8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT 4WD (235 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 100 Series [рест.]
2002–2005
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
174 kW
Max power at RPM
4800 RPM
Max trunk capacity
2212 l
Maximum torque
434 N*m
Min trunk capacity
1318 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
180 km/h
fuel
City driving fuel consumption per 100 km
21.5 l
Highway driving fuel consumption per 100 km
13.4 l
Mixed driving fuel consumption per 100 km
16.3 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1600 mm
Clearance
220 mm
Curb weight
2280 kg
Front track width
1605 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1940 mm
suspension
Back suspension
Dependent, spring
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
275/70 R16
other
Body type
Crossover
Disc size
8x16 ET60, 8x17 ET60, 8x18 ET60
Number of seater
5, 8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT 4WD (273 hp)
Привід Rear wheel drive
КПП Automatic
4Runner 4
2005–2009
273 hp
engine
Compression ratio
10
Cylinder bore
94.0 mm
Engine power
273 hp
Fuel tank capacity
87 l
Max power (kW)
200 kW
Max power at RPM
4800 RPM
Max trunk capacity
2127 l
Maximum torque
427 N*m
Min trunk capacity
1195 l
Stroke cycle
84.0 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
8.0 s
Max speed
188 km/h
fuel
City driving fuel consumption per 100 km
14.7 l
Cruising range
from 550 to 700 km
Highway driving fuel consumption per 100 km
11.8 l
Mixed driving fuel consumption per 100 km
14.5 l
transmission
Drive wheels
Rear wheel drive
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1575 mm
Clearance
240 mm
Curb weight
1955 kg
Front track width
1575 mm
Full weight
2382 kg
Height
1755 mm
Length
4800 mm
Number of doors
5
Wheelbase
2790 mm
Width
1875 mm
suspension
Back suspension
Dependent, spring
Front brakes
Disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
265/70 R16
other
Body type
Crossover
Front track
1575 mm
Number of seater
5, 8
Pitch Circle Diameter
DIA106 6x139.7 mm
Rear track
1575 mm
Turning circle
11.4 m
4.7 AT 4WD (282 hp)
Привід All wheel drive (AWD)
КПП Automatic
Tundra 1 [рест.]
2002–2006
282 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
282 hp
Fuel tank capacity
100 l
Max power (kW)
207 kW
Max power at RPM
4800 RPM
Maximum torque
440 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
fuel
City driving fuel consumption per 100 km
15.7 l
Cruising range
from 550 to 680 km
Highway driving fuel consumption per 100 km
13.1 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1648 mm
Clearance
274 mm
Curb weight
2037 kg
Front track width
1681 mm
Full weight
5352 kg
Height
1796 mm
Length
5545 mm
Number of doors
2
Wheelbase
3259 mm
Width
1910 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Front track
1674 mm
Number of seater
4
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1648 mm
4.7 AT 4WD (282 hp)
Привід All wheel drive (AWD)
КПП Automatic
Tundra 1 [рест.]
2006–2006
282 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
282 hp
Fuel tank capacity
100 l
Max power (kW)
207 kW
Max power at RPM
4800 RPM
Maximum torque
440 N*m
Min trunk capacity
2625 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
fuel
City driving fuel consumption per 100 km
15.7 l
Cruising range
from 650 to 770 km
Highway driving fuel consumption per 100 km
13.1 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1648 mm
Clearance
274 mm
Curb weight
2143 kg
Front track width
1674 mm
Full weight
5352 kg
Height
1816 mm
Length
5545 mm
Number of doors
4
Wheelbase
3259 mm
Width
1910 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Front track
1674 mm
Number of seater
5
Payload
3209 kg
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1648 mm
4.7 AT AWD (235 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 100 Series [рест.]
2002–2005
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
2212 l
Maximum torque
434 N*m
Min trunk capacity
1318 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
21.5 l
Highway driving fuel consumption per 100 km
13.4 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
5
dimensions
Back track width
1615 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1620 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1940 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Right
Wheel size
275/70 R16
other
Body type
Crossover
Number of seater
8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 MT (245 hp)
Привід All wheel drive (AWD)
КПП Manual
Tundra 1 [рест.]
2002–2004
245 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
245 hp
Fuel tank capacity
100 l
Max power (kW)
180 kW
Max power at RPM
4800 RPM
Maximum torque
434 N*m
Min trunk capacity
2625 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
6.8 s
Max speed
180 km/h
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
5
dimensions
Back track width
1648 mm
Clearance
274 mm
Front track width
1674 mm
Height
1816 mm
Length
5545 mm
Number of doors
4
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
ventilated disc
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 MT (245 hp)
Привід All wheel drive (AWD)
КПП Manual
Tundra 1 [рест.]
2002–2006
245 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
245 hp
Fuel tank capacity
100 l
Max power (kW)
180 kW
Max power at RPM
4800 RPM
Maximum torque
434 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
6.8 s
Max speed
180 km/h
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
5
dimensions
Back track width
1648 mm
Clearance
274 mm
Front track width
1681 mm
Height
1796 mm
Length
5545 mm
Number of doors
2
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
ventilated disc
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
4
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 MT (271 hp)
Привід All wheel drive (AWD)
КПП Manual
Tundra 1 [рест.]
2002–2006
271 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
271 hp
Fuel tank capacity
100 l
Max power (kW)
199 kW
Max power at RPM
4800 RPM
Maximum torque
427 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1648 mm
Clearance
274 mm
Curb weight
1887 kg
Front track width
1681 mm
Height
1796 mm
Length
5545 mm
Number of doors
2
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
ventilated disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
4
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 MT (271 hp)
Привід All wheel drive (AWD)
КПП Manual
Tundra 1 [рест.]
2002–2006
271 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
271 hp
Fuel tank capacity
100 l
Max power (kW)
199 kW
Max power at RPM
4800 RPM
Maximum torque
427 N*m
Min trunk capacity
2625 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1648 mm
Clearance
274 mm
Curb weight
1887 kg
Front track width
1674 mm
Height
1816 mm
Length
5545 mm
Number of doors
4
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
ventilated disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 MT (282 hp)
Привід All wheel drive (AWD)
КПП Manual
Tundra 1 [рест.]
2002–2006
282 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
282 hp
Fuel tank capacity
100 l
Max power (kW)
207 kW
Max power at RPM
4800 RPM
Maximum torque
440 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
fuel
City driving fuel consumption per 100 km
15.5 l
Highway driving fuel consumption per 100 km
13.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1648 mm
Clearance
274 mm
Curb weight
1887 kg
Front track width
1681 mm
Height
1796 mm
Length
5545 mm
Number of doors
2
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
ventilated disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
4
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 MT 4WD (235 hp)
Привід All wheel drive (AWD)
КПП Manual
Land Cruiser 100 Series [рест.]
2002–2005
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
2212 l
Maximum torque
434 N*m
Min trunk capacity
1318 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.7 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
22.4 l
Highway driving fuel consumption per 100 km
13.3 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
5
dimensions
Back track width
1600 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1605 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1940 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
275/70 R16
other
Body type
Crossover
Disc size
8x16 ET60, 8x17 ET60, 8x18 ET60
Number of seater
5, 8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 MT 4WD (282 hp)
Привід All wheel drive (AWD)
КПП Manual
Tundra 1 [рест.]
2006–2006
282 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
282 hp
Fuel tank capacity
100 l
Max power (kW)
210 kW
Max power at RPM
5400 RPM
Maximum torque
440 N*m
Min trunk capacity
2625 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
11.0 s
Max speed
190 km/h
fuel
City driving fuel consumption per 100 km
15.5 l
Cruising range
from 650 to 770 km
Highway driving fuel consumption per 100 km
13.0 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
6
dimensions
Back track width
1648 mm
Clearance
284 mm
Curb weight
2143 kg
Front track width
1674 mm
Full weight
5000 kg
Height
1816 mm
Length
5545 mm
Number of doors
4
Wheelbase
3259 mm
Width
1910 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Front track
1674 mm
Number of seater
5
Payload
3209 kg
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1648 mm
4.7 AT (243 hp)
Привід All wheel drive (AWD)
КПП Automatic
Sequoia 1
2000–2004
243 hp
engine
Compression ratio
9.6
Cylinder bore
94.0 mm
Engine power
243 hp
Fuel tank capacity
94 l
Max power (kW)
179 kW
Max power at RPM
4800 RPM
Max trunk capacity
3627 l
Maximum torque
427 N*m
Min trunk capacity
787 l
Stroke cycle
84.0 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
12.8 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
23.0 l
Highway driving fuel consumption per 100 km
13.9 l
Mixed driving fuel consumption per 100 km
16.8 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1679 mm
Clearance
250 mm
Curb weight
2300 kg
Front track width
1674 mm
Full weight
2993 kg
Height
1859 mm
Length
5179 mm
Number of doors
5
Wheelbase
3000 mm
Width
1940 mm
suspension
Back suspension
Semi-dependent, spring
Front brakes
Disc
Rear brakes
Disc
Steering wheel position
Left
Wheel size
245/70 R16
other
Body type
Crossover
Number of seater
5, 8
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 AT (245 hp)
Привід All wheel drive (AWD)
КПП Automatic
Tundra 1
2000–2002
245 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
245 hp
Fuel tank capacity
100 l
Max power (kW)
183 kW
Max power at RPM
4800 RPM
Maximum torque
427 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
13.5 s
Max speed
185 km/h
fuel
City driving fuel consumption per 100 km
16.8 l
Cruising range
from 550 to 720 km
Highway driving fuel consumption per 100 km
13.8 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1648 mm
Clearance
274 mm
Curb weight
2049 kg
Front track width
1682 mm
Full weight
2744 kg
Ground clearance
274 mm
Height
1796 mm
Length
5525 mm
Number of doors
4
Wheelbase
3259 mm
Width
1910 mm
suspension
Back suspension
Independent, spring
Front brakes
Disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16
other
Body type
Pickup
Front track
1682 mm
Number of seater
5
Payload
872 kg
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1648 mm
4.7 AT 4WD (245 hp)
Привід All wheel drive (AWD)
КПП Automatic
Tundra 1
1999–2002
245 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
245 hp
Fuel tank capacity
100 l
Max power (kW)
180 kW
Max power at RPM
4800 RPM
Maximum torque
434 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
7.8 s
Max speed
170 km/h
fuel
City driving fuel consumption per 100 km
16.8 l
Cruising range
from 550 to 680 km
Highway driving fuel consumption per 100 km
13.4 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1648 mm
Clearance
274 mm
Curb weight
1933 kg
Front track width
1682 mm
Full weight
2812 kg
Ground clearance
274 mm
Height
1796 mm
Length
5525 mm
Number of doors
2
Wheelbase
3259 mm
Width
1910 mm
suspension
Back suspension
Independent, spring
Front brakes
Disc
Rear brakes
drum
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Front track
1674 mm
Number of seater
4
Payload
879 kg
Pitch Circle Diameter
DIA106.1 6x139.7 mm
Rear track
1648 mm
4.7 MT (245 hp)
Привід All wheel drive (AWD)
КПП Manual
Tundra 1
1999–2002
245 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
245 hp
Fuel tank capacity
100 l
Max power (kW)
180 kW
Max power at RPM
4800 RPM
Maximum torque
434 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
6.9 s
Max speed
190 km/h
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
5
dimensions
Back track width
1648 mm
Clearance
274 mm
Front track width
1682 mm
Height
1796 mm
Length
5525 mm
Number of doors
4
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
Disc
Steering wheel position
Left
Wheel size
245/70 R16
other
Body type
Pickup
Number of seater
5
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 MT (245 hp)
Привід All wheel drive (AWD)
КПП Manual
Tundra 1
1999–2002
245 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
245 hp
Max power (kW)
180 kW
Max power at RPM
4800 RPM
Maximum torque
434 N*m
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
6.9 s
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
5
dimensions
Back track width
1648 mm
Clearance
274 mm
Front track width
1682 mm
Height
1796 mm
Length
5525 mm
Number of doors
2
Wheelbase
3259 mm
Width
1910 mm
suspension
Front brakes
Disc
Steering wheel position
Left
Wheel size
245/70 R16, 265/65 R17
other
Body type
Pickup
Number of seater
4
Pitch Circle Diameter
DIA106.1 6x139.7 mm
4.7 AT 4WD (235 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 100 Series
1998–2002
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
1370 l
Maximum torque
434 N*m
Min trunk capacity
830 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
21.5 l
Highway driving fuel consumption per 100 km
13.4 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1615 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1620 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1620 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Right
Wheel size
275/70 R16
other
Body type
Crossover
Disc size
8x16 ET60, 8x17 ET60, 8x18 ET60
Number of seater
8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT 4WD (235 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 100 Series
1998–2002
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
172 kW
Max power at RPM
4800 RPM
Max trunk capacity
1370 l
Maximum torque
434 N*m
Min trunk capacity
830 l
Stroke cycle
84 mm
Turnover of maximum torque
3400 RPM
performance
Acceleration (0-100 km/h)
11.7 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
22.4 l
Highway driving fuel consumption per 100 km
13.3 l
Mixed driving fuel consumption per 100 km
18.1 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1615 mm
Clearance
220 mm
Curb weight
2465 kg
Front track width
1620 mm
Full weight
3260 kg
Height
1880 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1940 mm
suspension
Back suspension
Dependent, spring
Front brakes
ventilated disc
Rear brakes
Disc
Steering wheel position
Left/Right
Wheel size
275/70 R16
other
Body type
Crossover
Disc size
8x16 ET60, 8x17 ET60, 8x18 ET60
Number of seater
5, 8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 AT AWD (235 hp)
Привід All wheel drive (AWD)
КПП Automatic
Land Cruiser 100 Series
1998–2002
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
1370 l
Maximum torque
434 N*m
Min trunk capacity
830 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.2 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
21.5 l
Highway driving fuel consumption per 100 km
13.4 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Automatic
Number of gear
4
dimensions
Back track width
1615 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1620 mm
Full weight
3260 kg
Height
1890 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1620 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Right
Wheel size
275/70 R16
other
Body type
Crossover
Number of seater
8
Pitch Circle Diameter
DIA110 5x150 mm
4.7 MT 4WD (235 hp)
Привід All wheel drive (AWD)
КПП Manual
Land Cruiser 100 Series
1998–2002
235 hp
engine
Compression ratio
9.6
Cylinder bore
94 mm
Engine model
2uz-fe
Engine power
235 hp
Fuel tank capacity
96 l
Max power (kW)
173 kW
Max power at RPM
4800 RPM
Max trunk capacity
1370 l
Maximum torque
434 N*m
Min trunk capacity
830 l
Stroke cycle
84 mm
Turnover of maximum torque
3600 RPM
performance
Acceleration (0-100 km/h)
11.7 s
Max speed
175 km/h
fuel
City driving fuel consumption per 100 km
22.4 l
Highway driving fuel consumption per 100 km
13.3 l
Mixed driving fuel consumption per 100 km
16.6 l
transmission
Drive wheels
All wheel drive (AWD)
Gearbox type
Manual
Number of gear
5
dimensions
Back track width
1615 mm
Clearance
220 mm
Curb weight
2260 kg
Front track width
1620 mm
Full weight
3260 kg
Height
1880 mm
Length
4890 mm
Number of doors
5
Wheelbase
2850 mm
Width
1940 mm
suspension
Back suspension
Independent, spring
Front brakes
ventilated disc
Rear brakes
ventilated disc
Steering wheel position
Left/Right
Wheel size
275/70 R16
other
Body type
Crossover
Disc size
8x16 ET60, 8x17 ET60, 8x18 ET60
Number of seater
5, 8
Pitch Circle Diameter
DIA110 5x150 mm
Cars with the 2UZ-FE engine
This engine was fitted to 5 models
| Photo | Brand | Model | Generation | Production years |
|---|---|---|---|---|
|
No photo
|
Lexus | LS | LS III (XF30) | 2001 - 2006 |
|
No photo
|
Lexus | LX | LX II (J100) | 1998 - 2007 |
|
No photo
|
Toyota | Land Cruiser | Land Cruiser 100 GX | 1998 - 2006 |
|
No photo
|
Toyota | Land Cruiser | Land Cruiser 100 VX | 1998 - 2007 |
|
Toyota | Sequoia | Sequoia | 2001 - 2007 |
|
Toyota | Tundra | Tundra | 1999 - 2006 |
All modifications (16)
| Vehicle | Generation | Modification | Power | Gearbox | Drive |
|---|---|---|---|---|---|
| Lexus LS | LS III (XF30) | 3.0 V6 220 л.с. 5-Автомат 2WD | 220 hp | 5-Автомат | 2WD |
| Lexus LS | LS III (XF30) | 3.0 V6 220 л.с. 6-Автомат 2WD | 220 hp | 6-Автомат | 2WD |
| Lexus LX | LX II (J100) | 4.7 V8 238 л.с. 5-Автомат 4x4 | 238 hp | 5-Автомат | 4x4 |
| Lexus LX | LX II (J100) | 4.7 V8 238 л.с. 6-Автомат 4x4 | 238 hp | 6-Автомат | 4x4 |
| Lexus LX | LX II (J100) | 4.7 V8 280 л.с. 5-Автомат 4x4 | 280 hp | 5-Автомат | 4x4 |
| Lexus LX | LX II (J100) | 4.7 V8 280 л.с. 6-Автомат 4x4 | 280 hp | 6-Автомат | 4x4 |
| Toyota Land Cruiser | Land Cruiser 100 GX | 4.7 V8 235 л.с. 5-Автомат 4x4 | 235 hp | 5-Автомат | 4x4 |
| Toyota Land Cruiser | Land Cruiser 100 GX | 4.7 V8 235 л.с. 6-Автомат 4x4 | 235 hp | 6-Автомат | 4x4 |
| Toyota Land Cruiser | Land Cruiser 100 VX | 4.7 V8 235 л.с. 5-Автомат 4x4 | 235 hp | 5-Автомат | 4x4 |
| Toyota Land Cruiser | Land Cruiser 100 VX | 4.7 V8 235 л.с. 6-Автомат 4x4 | 235 hp | 6-Автомат | 4x4 |
| Toyota Sequoia | Sequoia | 4.7 V8 282 л.с. 5-Автомат 2WD | 282 hp | 5-Автомат | 2WD |
| Toyota Sequoia | Sequoia | 4.7 V8 282 л.с. 5-Автомат 4x4 | 282 hp | 5-Автомат | 4x4 |
| Toyota Tundra | Tundra | 4.7L V8 240 л.с. 5-Автомат 2WD | 240 hp | 5-Автомат | 2WD |
| Toyota Tundra | Tundra | 4.7L V8 240 л.с. 5-Автомат 4x4 | 240 hp | 5-Автомат | 4x4 |
| Toyota Tundra | Tundra | 4.7L V8 282 л.с. 6-Автомат 2WD | 282 hp | 6-Автомат | 2WD |
| Toyota Tundra | Tundra | 4.7L V8 282 л.с. 6-Автомат 4x4 | 282 hp | 6-Автомат | 4x4 |
Interesting Facts
- The 2UZ-FE is known for its durability and reliability.
- It is often used in heavy-duty applications due to its robust design.
Applications
Total produced: загальна кількість випущених двигунів
| Vehicle | Generation | Years | Power | Markets |
|---|---|---|---|---|
| Toyota Land Cruiser | J100 | 1998-2007 | 230hp/300hp | Worldwide |
| Toyota Tundra | First Generation | 2000-2006 | 240hp/300hp | North America |
Compatible transmissions: 4-speed Automatic, 5-speed Automatic
Drive types: RWD, AWD
Fuel Economy
| Fuel Type | Petrol 95 |
| Octane Rating | Minimum: 91 | Recommended: 95 |
| Consumption (City) | 15 L/100km |
| Consumption (Highway) | 10 L/100km |
| Consumption (Combined) | 12 L/100km |
| Real Consumption | 13.5 L/100km |
| Fuel Tank Capacity | 90 L |
| Range | 750 km |
| Cost per 100 km | 15-20 USD |
Emissions Standards
| Emission Standard | Euro 3 |
| CO₂ Emissions | 290 g/km |
| Particulate Filter (DPF) | Absent |
| AdBlue | Not Required |
Comparison with competitors
| Engine | Brand | Displacement | Power | Torque |
|---|---|---|---|---|
| 5.4L Triton V8 | Ford | 5,400 cc | 300 hp | 400 Nm |
| 4.7L V8 | Chrysler | 4,700 cc | 235 hp | 400 Nm |
Pros
- High reliability and longevity
- Strong torque output
- Good performance in off-road conditions
Cons
- Higher fuel consumption compared to smaller engines
- Limited tuning potential due to stock internals
